16.1.2. Replacement Parts List
<Model: CS-ME7CKPG / CS-ME10CKPG / CS-ME12CKPG / CS-ME14CKPG / CS-ME18CKPG>
Ref.
No.
Part Name & Description Q’ty Part No. Remarks
CS-ME7CKPG CS-ME10CKPG CS-ME12CKPG CS-ME14CKPG CS-ME18CKPG
1 TERMINAL BOARD COMPLETE 1 CWA28K1045
←
←←
← ←
←←
← ←
←←
← ←
←←
← ●
●●
●
2 SENSOR COMPLETE (PIPE) 1 CWA50C2101
←
←←
← ←
←←
← ←
←←
← ←
←←
← ●
●●
●
3 SENSOR COMPLETE (INTAKE) 1 CWA50C2103
←
←←
← ←
←←
← ←
←←
← ←
←←
← ●
●●
●
4 PC BOARD (MAIN) 1 CWA73C1332 CWA73C1333 CWA73C1334 CWA73C1335 CWA73C1336
●
●●
●
5 PC BOARD (RECEIVER) 1 CWA742895
←
←←
← ←
←←
← ←
←←
← ←
←←
← ●
●●
●
6 PC BOARD (DISPLAY) 1 CWA742894
←
←←
← ←
←←
← ←
←←
← ←
←←
← ●
●●
●
7 REMOTE CONTROL CONPLETE 1 CWA75C2311
←
←←
← ←
←←
← ←
←←
← ←
←←
← ●
●●
●
8 FAN MOTOR 1 CWA981056
←
←←
← ←
←←
← ←
←←
←
CWA981073
●
●●
●
9 MOTOR-AIR SWING 1 CWA98259X
←
←←
← ←
←←
← ←
←←
← ←
←←
← ●
●●
●
11 FRONT GRILLE COMPLETE 1 CWE11C2681
←
←←
← ←
←←
← ←
←←
← ←
←←
← ●
●●
●
12 DISCHARGE GRILLE COMPLETE 1 CWE20C2174
←
←←
← ←
←←
← ←
←←
← ←
←←
←
14 CROSS-FLOW FAN COMPLETE 1 CWH02K1016
←
←←
← ←
←←
← ←
←←
← ←
←←
←
15 HOLDER CORD 1 CWH31103
←
←←
← ←
←←
← ←
←←
← ←
←←
←
16 HOLDER SENSOR 1 CWH32137
←
←←
← ←
←←
← ←
←←
← ←
←←
←
17 HOLDER REMOTE CONTROL 1 CWH361008
←
←←
← ←
←←
← ←
←←
← ←
←←
←
21 CAP(FRONT GRILLE) 2 CWH521025B
←
←←
← ←
←←
← ←
←←
← ←
←←
←
22 NUT 1 CWH56081
←
←←
← ←
←←
← ←
←←
← ←
←←
←
23 SCREW SET 1 CWH82C1155
←
←←
← ←
←←
← ←
←←
← ←
←←
←
24 BELT 1 CWH881003
←
←←
← ←
←←
← ←
←←
← ←
←←
←
25 LEAD WIRE COMPLETE(AIR SWING) 1 CWMA60C0001
←
←←
← ←
←←
← ←
←←
← ←
←←
←
26 TERMINAL PLATE FOR EARTH 1 CWMA64C0001
←
←←
← ←
←←
← ←
←←
← ←
←←
←
27 EVAPORATOR 1 CWMB30C0020
←
←←
←
CWMB30C0019
←
←←
← ←
←←
←
28 AIR FILTER 2 CWMD000001
←
←←
← ←
←←
← ←
←←
← ←
←←
← ●
●●
●
29 CHASSIS COMPLETE 1 CWMD50C0014
←
←←
← ←
←←
← ←
←←
← ←
←←
←
30 PARTICULAR PLATE (EVA) 1 CWMD910002
←
←←
← ←
←←
← ←
←←
← ←
←←
←
31 PARTICULAR PLATE (DISPLAY) 1 CWMD930001
←
←←
← ←
←←
← ←
←←
← ←
←←
←
32 PARTICULAR PLATE (DISPLAY) 1 CWMD930002
←
←←
← ←
←←
← ←
←←
← ←
←←
←
33 PARTICULAR COVER (FAN MOTOR) 1 CWMD930003
←
←←
← ←
←←
← ←
←←
← ←
←←
←
34 PARTICULAR COVER (PIPE) 1 CWMD930009
←
←←
← ←
←←
← ←
←←
← ←
←←
←
35 GRILLE DOOR 1 CWME140001
←
←←
← ←
←←
← ←
←←
← ←
←←
←
36 INTAKE GRILLE 1 CWE22K1161
←
←←
← ←
←←
← ←
←←
← ←
←←
←
37 LOUVER 1 CWME240001
←
←←
← ←
←←
← ←
←←
← ←
←←
←
40 CONTROL BOARD BOX 1 CWH102172
←
←←
← ←
←←
← ←
←←
← ←
←←
←
41 CONTROL COVER-1 1 CWMH130001
←
←←
← ←
←←
← ←
←←
← ←
←←
←
42 CONTROL COVER-2 1 CWMH130002
←
←←
← ←
←←
← ←
←←
← ←
←←
←
43 CONTROL COVER-3 1 CWMH130003
←
←←
← ←
←←
← ←
←←
← ←
←←
←
44 INSTALLATION PLATE 1 CWMH36K0002
←
←←
← ←
←←
← ←
←←
← ←
←←
←
45 SHAFT FOR LOUVER 1 CWMH630001
←
←←
← ←
←←
← ←
←←
← ←
←←
←
46 TUBE ASSY 1 CWMT00C0015
←
←←
←
CWMT00C0005
←
←←
← ←
←←
←
47 DRAIN CAP 1 CWRH520001
←
←←
← ←
←←
← ←
←←
← ←
←←
←
48 FLUCRUM 1 CWRH64K0001
←
←←
← ←
←←
← ←
←←
← ←
←←
←
49 DRAIN HOSE 1 CWRH850001
←
←←
← ←
←←
← ←
←←
← ←
←←
←
50 FLARE NUT (1/4) 1 CWT25086
←
←←
← ←
←←
← ←
←←
← ←
←←
←
51 FLARE NUT (3/8) 1 CWT25087
←
←←
← ←
←←
← ←
←←
← ←
←←
←
54 ZNR 1 ERZVEAV201
←
←←
← ←
←←
← ←
←←
← ←
←←
←
55 ZNR 1 ERZVEAV511
←
←←
← ←
←←
← ←
←←
← ←
←←
←
56 FUSE (250V, 3A) 1 K5E312BB0002
←
←←
← ←
←←
← ←
←←
← ←
←←
←
(Note)
·
"●" marked parts are recommended to be kept in stock.
·
All parts are supplied from ACD, JAPAN (VENDER CODE : 00025800).
112
CS-ME7CKPG / CS-ME10CKPG / CS-ME12CKPG / CS-ME14CKPG / CS-ME18CKPG / CU-2E15CBPG / CU-2E18CBPG / CU-3E23CBPG / CU-4E27CBPG
