DMC-FT1EB/EE/EF/EG/EP/GC/GJ/GN/SG, TS1GH/GK/GT/P/PC/PU
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
------ P.C.B. LIST ------ R6406 ERJ2GEJ152 M.RESISTOR CH 1/16W 1.5K 1
## VEP56072B MAIN P.C.B. 1 (RTL) E.S.D. EB,EF,EG,EP
## VEP56072A MAIN P.C.B. 1 (RTL) E.S.D. EE,GC,GJ,GN, S6401 K0G177A00001 SWITCH 1
SG,GH,GK,GT,P,PC,PU S6402 K0F111A00541 SWITCH 1
## VEP58075A FLASH P.C.B. 1 (RTL) E.S.D. S6403 K0F111A00541 SWITCH 1
## VEP50033A TOP P.C.B. 1 (RTL) E.S.D. S6404 K0F111A00539 SWITCH 1
## VEP50034A REAR OPERATION P.C.B. 1 (RTL) E.S.D. S6405 K0F111A00541 SWITCH 1
S6406 K0F111A00541 SWITCH 1
------ OTHER ELEC. ------ S6407 K0F111A00541 SWITCH 1
 B6402 ML-421S/ZTK BUTTON BATTERY 1 [ENAGY] S6408 K0F111A00541 SWITCH 1
C8001 F2A2F9000003 CAPACITOR 1 S6409 K0F111A00541 SWITCH 1
S6410 K0F111A00539 SWITCH 1
--- INDIVIDUAL PARTS ---
## VEP58075A FLASH P.C.B. (RTL) E.S.D. ZB6401 K3ZZ00200042 BATTERY HOLDER 1
C8002 F1K2J102A028 C.CAPACITOR 630V 1000P 1
C8003 F1G1A104A012 C.CAPACITOR CH 10V 0.1U 1
C8004 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C8005 F1J0J106A020 C.CAPACITOR CH 6.3V 10U 1
C8006 F1K2E4730005 C.CAPACITOR 250V 0.047U 1
D8002 B0EDAT000002 DIODE 1 E.S.D.
 F8001 ERBSE1R50U FUSE 32V 1.5A 1
 F8002 ERBSE1R25U FUSE 32V 1.25A 1
FP8001 K1MN19BA0209 CONNECTOR 19P 1
FP8002 K4ZZ04000051 CONNECTOR 4P 1
IC8001 C0ZBZ0001636 IC 1 E.S.D.
L8001 G5F1A0000026 CHIP INDUCTOR 1
Q8001 B1DFCG000020 TRANSISTOR 1 E.S.D.
Q8002 B1JBLP000022 TRANSISTOR 1 E.S.D.
R8001 ERJ3GEYJ330 M.RESISTOR CH 1/10W 33 1
R8002 ERJ8GEYJ105V M.RESISTOR CH 1/8W 1M 1
R8003 ERJ6RED105 M.RESISTOR CH 1/16W 1M 1
R8004 ERJ6RED105 M.RESISTOR CH 1/16W 1M 1
R8005 ERJ2RHD153X M.RESISTOR CH 1/16W 15K 1
R8008 ERJ2GEJ153 M.RESISTOR CH 1/16W 15K 1
R8010 ERJ3GEYJ104 M.RESISTOR CH 1/10W 100K 1
T8001 G5D1A0000066 TRANSFORMER 1
## VEP50033A TOP P.C.B. (RTL) E.S.D.
D6301 LNJ0S2F8BRA1 DIODE 1 E.S.D.
ET6301 K4AC01D00001 EARTH SPRING 1
ET6302 K4AC01D00001 EARTH SPRING 1
LB6301 J0JCC0000415 FILTER 1
M6301 L0CBAA000012 MICROPHONE UNITS 1
R6301 D0YAR0000007 M.RESISTOR CH 1/16W 0 1
S6301 K0F111A00539 SWITCH 1
S6302 K0F212A00003 SWITCH 1
VA6301 D4ED18R00004 VARISTORS 1
## VEP50034A REAR OPERATION P.C.B. (RTL) E.S.D.
D6401 B3ABB0000150 DIODE 1 E.S.D.
R6401 ERJ2GEJ473 M.RESISTOR CH 1/16W 47K 1
R6402 ERJ2GEJ223 M.RESISTOR CH 1/16W 22K 1
R6403 ERJ2GEJ123 M.RESISTOR CH 1/16W 12K 1
R6404 ERJ2RHD682X M.RESISTOR CH 1/16W 6.8K 1
R6405 ERJ2GEJ332 M.RESISTOR CH 1/16W 3.3K 1
S-12
