DMC-FT1EB/EE/EF/EG/EP/GC/GJ/GN/SG, TS1GH/GK/GT/P/PC/PU
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
1 VKM7954 REAR ALUMI CASE 1 (-A) B1 VHD2067 SCREW 1
1 VKM7760 REAR ALUMI CASE 1 (-S) B2 VHD2067 SCREW 1
1 VKM7768 REAR ALUMI CASE 1 (-D) B3 VHD2067 SCREW 1
1 VKM7769 REAR ALUMI CASE 1 (-G) B4 VHD2067 SCREW 1
2 VMP9267 LENS PLATE 1 B5 VHD2075 SCREW 1
3 VQL1Y51 BATT DOOR CAUTION LABEL 1 EB,EE,EF,EG,EP,GC,GJ,GN, B6 VHD2075 SCREW 1
SG,GH,GT,P,PU B7 VHD2075 SCREW 1
3 VQL1Y53 BATT DOOR CAUTION LABEL 1 GK B8 VHD2075 SCREW 1
3 VQL1Y52 BATT DOOR CAUTION LABEL 1 PC B9 VHD2076 SCREW 1
4 VXW1029 LENS UNIT 1 B10 VHD2076 SCREW 1
5 VYK3H57 REAR CASE (1) 1 B11 VHD1909 SCREW 1
7 VMP9316 REAR FPC PLATE 1 B12 VHD1909 SCREW 1
8 VYK3E16 LCD ASSY 1 B13 VHD1909 SCREW 1
9 VYK3H61 MODE DIAL (1) 1 B14 VHD1909 SCREW 1
12 VMP9328 MODE DIAL PIECE 1 B15 VHD1909 SCREW 1
13 VEP50034A REAR OPERATION P.C.B. 1 (RTL) E.S.D. B16 VHD1909 SCREW 1
14 VGQ0E07 MODE DIAL ARM 1 B17 VHD1909 SCREW 1
15 VGU0D92 REAR BUTTON DISPLAY 1 B18 VHD1909 SCREW 1
16 VGU0D93 REAR BUTTON CENTER 1 B19 VHD1909 SCREW 1
17 VGU0D94 REAR BUTTON CROSS 1 B20 VHD1909 SCREW 1
18 VGU0D95 REAR BUTTON PLAY 1 B21 VHD1909 SCREW 1
19 VGU0D96 REAR BUTTON REC 1 B22 VHD1909 SCREW 1
20 VGU0E31 REAR BUTTON Q.MENU 1 B23 VHD1909 SCREW 1
22 VYK3H58 FRONT CASE (1) 1 (-A) B24 VHD1886 SCREW 1
22 VYK3H56 FRONT CASE (1) 1 (-S) B25 VHD1694 SCREW 1
22 VYK3H59 FRONT CASE (1) 1 (-D) B26 VHD1681 SCREW 1
22 VYK3H60 FRONT CASE (1) 1 (-G) B27 VHD1681 SCREW 1
23 L0AA01A00032 SPEAKER 1 B28 XQN16+BJ4FN SCREW 1
24 VEP56072B MAIN P.C.B. 1 (RTL) E.S.D. EB,EF,EG,EP B29 VHD2117 SCREW 1
24 VEP56072A MAIN P.C.B. 1 (RTL) E.S.D. EE,GC,GJ,GN, B30 VHD2117 SCREW 1
SG,GH,GK,GT,P,PC,PU B31 VHD2085 SCREW 1
25 VGQ0C16 ZOOM SLIDE LEVER 1 B32 VHD2078 SCREW 1
26 VGQ0F67 PCB SPECER 1 B33 VHD2074 SCREW 1
27 VGU0D87 SHUTTER BUTTON 1 B34 VHD2077 SCREW 1
28 VGU0D88 POWER BUTTON 1 B35 VHD2077 SCREW 1
30 VWJ2075 FPC 1 B36 VHD1909 SCREW 1
31 VGQ0C17 BATTERY CASE 1 B37 VHD1909 SCREW 1
32 VGQ0C32 TOP BARRIER TAPE 1 B38 VHD1909 SCREW 1
33 VGQ0D32 BATT DETECT LEVER 1 B39 VHD1909 SCREW 1
34 VGU0D86 BATT LOCK KNOB 1 B40 VHD1909 SCREW 1
35 VMB4094 BATTERY OUT SPRING 1 B41 VHD1909 SCREW 1
36 VMB4226 BATT LOCK SPRING 1 B42 XQN16+BJ4FN SCREW 1
37 VMB4240 BATT DETECT SPRING 1 B43 XQN16+BJ4FN SCREW 1
38 VMC2074 FL EARTH PLATE 1 B44 XQN16+BJ4FN SCREW 1
39 VMP9269 BATT LOCK PLATE 1 B45 XQN16+BJ4FN SCREW 1
41 VEK0N46 FLASH U 1 B46 XQN16+BJ4FN SCREW 1
42 VEP58075A FLASH P.C.B. 1 (RTL) E.S.D. B47 VHD2074 SCREW 1
43 VMB4253 CONDENSER EARTH SPRING 1 B48 VHD2078 SCREW 1
44 VGU0D90 JACK DOOR KNOB 1 B49 VHD1681 SCREW 1
46 VMB4227 BATT DOOR KNOB SPRING 1 B50 VHD2076 SCREW 1
47 VQL1V63 JACK DOOR LOCK LABEL 1 B51 XQN16+BJ4FN SCREW 1
49 VGQ0C15 ZOOM SLIDE PIECE 1
50 VGU0D85 ZOOM KNOB 1
51 VKM7761 TOP ORNAMENT 1 (DMC-FT1)
P VUMG1863 WATERPROOF PACKING KIT
1 (Including Ref No.from
51 VKM7956 TOP ORNAMENT 1 (DMC-TS1) "P-1 upto "P-8")
52 VMB4230 BATTT DOOR SPRING 1 P-1 ---------- SCREW O RING 1 (Included in VUMG1863)
54 VGQ0C31 BATT DOOR LOCK LABEL 1 P-2 ---------- JACK DOOR BONDING ASSY 1 (Included in VUMG1863)
55 VGU0D89 BATT DOOR KNOB 1 P-3 ---------- BATT DOOR PACKING 1 (Included in VUMG1863)
56 VKF4532 BATT DOOR 1 (-A) P-4 ---------- SCREW O RING 1 (Included in VUMG1863)
56 VKF4443 BATT DOOR 1 (-S) P-5 ---------- TOP BUTTON PACKING 1 (Included in VUMG1863)
56 VKF4445 BATT DOOR 1 (-D) P-6 ---------- CASE O-RING 1 (Included in VUMG1863)
56 VKF4446 BATT DOOR 1 (-G) P-7 ---------- MODE DIAL O-RING 1 (Included in VUMG1863)
58 VQL1V65 BATTERY LABEL 1 P-8 ---------- REAR BUTTON PACKING 1 (Included in VUMG1863)
59 VYK3B57 BATT DOOR PLATE U 1
60 VEP50033A TOP P.C.B. 1 (RTL) E.S.D.
61 VMP9270 TOP FPC PLATE 1
62 VMB4225 ZOOM SPRING 1
63 VMB4225 ZOOM SPRING 1
64 ML-421S/ZTK BUTTON BATTERY 1 [Enagy](B6402)
65 F2A2F9000003 CAPACITOR 1 (C8001)
66 VGQ0F41 EMC DPR SHEET 1
67 VGQ0F66 BARRIER SHEET 1
70 VMC2077 TOP EARTH PLATE 1
71 VGQ0F65 LENS BARRIER SHEET 1
72 VGQ0F42 EMC BUSTERRAID SHEET 1
