Panasonic DMR-EH50

32
RQT8033
Playing back
Playing recorded video contents/Playing play-only discs
Preparation
≥Turn on the television and select the appropriate video input to suit
the connections to this unit.
≥Turn on this unit.
1 Press [HDD] or [DVD] to select the
playback drive.
The HDD or DVD indicator lights up on the unit.
≥It is possible to watch playback from one drive while
recording on another (editing is not possible).
2 If you selected the DVD drive
Press [< OPEN/CLOSE] on the main
unit to open the tray and insert a disc.
≥Press the button again to close the tray.
≥When using 8 cm DVD-RAM, or 8 cm DVD-R, remove the
disc from the cartridge.
3 Press [1](PLAY).
[HDD] [RAM] [-R] [-RW‹V›] [+R] [-RW‹V›]
Play starts from the most recently recorded
title.
[DVD-V] [DVD-A] [CD] [VCD]
Play starts from the beginning of the disc.
≥When using cartridge discs with the write-protect tab in the
protect position (➡ 52), play automatically starts when
inserted in the unit.
∫ Selecting recorded programmes (titles) to play—
Direct Navigator
[HDD] [RAM] [-R] [-RW‹V›] [+R] [-RW‹VR›]
1 Press [DIRECT NAVIGATOR].
Switching the Direct Navigator appearance
1 Press [SUB MENU] while Thumbnail Display is displayed.
2 Press [3, 4] to select “Table Display” and press [ENTER].
≥The display appearance last used is saved even after the unit is
turned off.
2 [HDD] [RAM]
Press [A] to select “VIDEO”.
[HDD] To sort Title View for easy searching (Table Display only)
This function is convenient when searching for one title to
playback from many titles.
1Press [SUB MENU].
2Press [3, 4] to select “Sort” and press [ENTER].
3Press [3, 4] to select the item and press [ENTER].
If you select an item other than “No.”
≥The Direct Navigator screen will reappear after playback of the
selected title has finished. (You cannot play titles continuously.)
≥Skip and Time Slip will only function with the title currently being
played back.
≥If you exit the Direct Navigator screen, or switch to “PICTURE”
Direct Navigator screen, the sorted Title View will be cancelled.
3Press [3, 4, 2, 1] to select the title and press
[ENTER].
You can also select titles with the numbered buttons.
To show other pages
Press [3, 4, 2, 1] to select “Previous” or “Next” and press
[ENTER]. (Thumbnail Display only)
≥You can also press [:, 9] to show other pages.
To exit the screen
Press [DIRECT NAVIGATOR].
Direct Navigator screen icons
DVD
HDD
HDD
DVD
DVD
SD
SD
1
2 3
4 5 6
7
8
9
P
R
O
G
/
C
H
E
C
K
D
I
S
P
L
A
Y
㧿
Í
Í
DIRECT TV REC
DIRECT TV REC
AV
AV
CH
CH
VOLUME
VOLUME
TV
TV
CH
CH
VIDEO Plus+
VIDEO Plus+
MANUAL SKIP
MANUAL SKIP
0
INPUT SELECT
INPUT SELECT
SKIP
SKIP
SLOW/SEARCH
SLOW/SEARCH
STOP
STOP
PAU SE
PAUSE
PLAY/x1.3
T
I
M
E
S
L
I
P
D
I
R
E
C
T
N
A
V
I
G
A
T
O
R
SUB MENU
SUB MENU
RETURN
RETURN
STATUS
STATUS
CREATE
CREATE
CHAPTER
CHAPTER
ERASE
ERASE
REC
REC
REC MODE
REC MODE
EXT LINK
EXT LINK
TIMER
TIMER
AUDIO
AUDIO
DVD/TV
ENTER
ENTER
CANCEL
CANCEL
T
O
P
F
U
N
C
T
I
O
N
S
A
B C
T
O
P
M
E
N
U
ERASE
DIRECT
NAVIGATOR,
TOP MENU
SUB MENU
:, 9
∫
MANUAL SKIP
W X CH
6, 5
3
RETURN
TIME SLIP
AUDIO, A
CREATE
CHAPTER
;
1
3,4,2,1
ENTER
2; , ;1
HDD
HDD
HDD DVD
DVD
DVD SD
EXT LINK
CH
DRIVE
SELECT
REC
S VIDEO IN VIDEO IN
L/MONO -AUDIO IN-
AV3
R
/k 1.3
1. 3
OPEN/CLOSE
2
1
∫
3
X CH W
Numbered
buttons
HDD, DVD indicator
Insert fully so it clicks into place.
Insert label-up.
Insert with the arrow
facing in.
∫ Cartridge disc
HDD
PLAY
DVD
SD
≥Thumbnail Display ≥Table Display
e.g., [HDD] [RAM] [-R] [-RW‹V›] [+R] [-RW‹VR›]
5: [0] ➡ [0] ➡ [5] 5: [0] ➡ [5]
15: [0] ➡ [1] ➡ [5] 15: [1] ➡ [5]
115: [1] ➡ [1] ➡ [5]
[ Currently recording.
Title protected.
Title that was not recorded due to recording
protection (Digital broadcasts etc.)
t
Title cannot be played
[When transferring (dubbing) a title to the HDD, or
when data is damaged etc.]
Titles that have been rerouted to the HDD
(➡ 29, Relief Recording)
Title with “One time only recording” restriction
(➡ 69, CPRM)
(NTSC)
(PAL)
Title recorded using a different encoding system from
that of the TV system currently selected on the unit.
≥Alter the “TV System” setting on this unit to suit
(➡ 62).
DIRECT NAVIGATOR TITLE VIEW
Previous Page 02/02 Next
BBC 10/10 FRI BBC 11/10 SAT
007 008
- - -
- - -- - -- - -
HDD
VIDEO
RETURN
ENTER
SUB MENU
S
Select
Previous
Next
A
B
DIRECT NAVIGATOR TITLE VIEW
Page 01/01
HDD
001
BBC 10/10 FRI 13:30
BBC2 10/10 FRI 9:25
AV2 4/10 SAT 16:10
BBC 3/10 FRI 22:05
AV2 3/10 FRI 20:00
BBC1 27/ 9 SAT 12:15
BBC 26/ 9 FRI 13:30
002
003
004
005
006
007
---
Name of titleTimeNo. Name Date Day
008
BBC 11/10 SAT 21:00
RETURN
ENTER
SUB MENU
S
Select
VIDEO
Rec Time
0:52(SP)
A
B
DIRECT NAVIGATOR TITLE VIEW
007 008
- - -
HDD
VIDEO
A
B
