DMR-EZ49VEBK vol.1
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
C38004 F1H1C104A071 16V 0.1U 1 C9750 F1H1C104A071 16V 0.1U 1
C9752 F1H1H4700006 50V 47P 1
IC38002 C0DBZHE00024 IC 1 E.S.D. C9753 F1H1H4700006 50V 47P 1
C9754 F1H1C104A071 16V 0.1U 1
P38003 K1FY104B0011 USB CONNECTOR(4P) 1 C9756 F1H1H101A004 50V 100P 1
P38004 K1KY06A00026 CONNECTOR(6P) 1 C9757 F1J0J475A008 6.3V 4.7U 1
C9759 F2A1C100A720 16V 10U 1
C9761 F1J1C1060001 16V 10U 1
C9766 F1H1C104A071 16V 0.1U 1
## VEP73175A HDMI P.C.B. (RTL) E.S.D. C9768 F2A1C470A722 16V 47U 1
C9771 F1H1A105A028 10V 1U 1
JK5601 K1FA119E0017 JACK, HDMI 1 C9772 F1H1A105A028 10V 1U 1
C9778 F1H1H103A219 50V 0.01U 1
L5601 J0MAB0000235 COIL 1 C9779 F1H1H103A219 50V 0.01U 1
L5602 J0MAB0000235 COIL 1 C9780 F1H1H103A219 50V 0.01U 1
C9781 F1H1H103A219 50V 0.01U 1
LB5601 J0JCC0000119 COIL 1 C9785 F2A1E470A205 25V 47U 1
LB5602 J0JCC0000119 COIL 1 C9793 F1H1H103A219 50V 0.01U 1
LB5603 J0JCC0000119 COIL 1 C9794 F1H1H103A219 50V 0.01U 1
LB5604 J0JCC0000119 COIL 1 C9795 F1H1H103A219 50V 0.01U 1
C10101 F1H1H221A004 50V 220P 1
P5601 K1KA20B00155 CONNECTOR(20P) 1 C11120 F0CAF104A021 100V 0.1P 1
C11121 F0CAF683A021 100V 0.068P 1
C11122 F1B2G1020002 400V 1000P 1
C11123 F1B2G1020002 400V 1000P 1
## RFKB71174A DIGITAL IF P.C.B. EZ49VEBK (RTL) E.S.D. C11124 F1B2G2220001 400V 2200P 1
## RFKB71174AT DIGITAL IF P.C.B. EZ49VECK, EZ49VEGK. C11143 F2B2W6800005 400V 68U 1
EZ49VEGS (RTL)E.S.D. C11150 F2A1E2210067 25V 220 1
C4001 F1H1H102A004 50V 1000P 1 C11151 F1B3D681A011 2000V 680P 1
C4002 F1H1H102A004 50V 1000P 1 C11152 F1H1H151A004 50V 150P 1
C4003 F1H1H102A004 50V 1000P 1 C11153 F1H1H222A013 50V 2200P 1
C4004 F1H1H102A004 50V 1000P 1 C11154 F1H1H102A004 50V 1000P 1
C7709 F1H1H104A748 50V 0.1U 1 C11160 F1B3A2220009 1000V 2200U 1
C7765 F2A1C2210095 16V 220U 1 C11200 F1H1C104A071 16V 0.1U 1
C7769 F1H1H392A013 50V 3900P 1 C11201 F1H1C104A071 16V 0.1U 1
C7770 F2A1V560A387 35V 56U 1 C11270 F2A1C1520021 16V 1500U 1
C7771 F2A1H100A454 50V 10U 1 C11271 F2A1C1520021 16V 1500U 1
C7772 F2A1C121A453 16V 120U 1 C11272 F2A1C1020095 16V 1000U 1
C7773 F2A1H100B034 50V 10U 1 C11273 F1H1C105A095 16V 1U 1
C9112 F1H1C104A071 16V 0.1U 1 C11274 F2A1C330B101 16V 33U 1
C9158 F1H1C104A071 16V 0.1U 1 C11370 F2A1A4700041 10V 47U 1
C9201 F1H1H221A004 50V 220P 1 C11371 F1H1C104A071 16V 0.1U 1
C9202 F1H1H221A004 50V 220P 1 C11372 F2A1A4700041 10V 47U 1
C9301 F1H1A105A028 10V 1U 1 C11701 F1J1C1060001 16V 10U 1
C9302 F1H1H103A219 50V 0.01U 1 C11702 F1J1C1060001 16V 10U 1
C9303 F1H1A105A028 10V 1U 1 C11703 F1H1C104A071 16V 0.1U 1
C9311 F1J1A475A023 10V 4.7U 1 C11704 F1H1C104A071 16V 0.1U 1
C9312 F1J1A475A023 10V 4.7U 1 C11705 F1H1H682A013 50V 6800P 1
C9701 F1J0J475A008 6.3V 4.7U 1 C11707 F1H1H103A219 50V 0.01U 1
C9703 F1J1C1060001 16V 10U 1 C11708 F2A1A6810022 10V 680U 1
C9704 F1H1H103A219 50V 0.01U 1 C11750 F1J0J106A020 6.3V 10U 1
C9706 F2A0J101A825 6.3V 100U 1 C11751 F1J0J106A020 6.3V 10U 1
C9707 F1H1C104A071 16V 0.1U 1 C11753 F2A1C1210022 16V 120P 1
C9708 F1H1H103A219 50V 0.01U 1 C14301 F1J1C1060001 16V 10U 1
C9713 F1H1C104A071 16V 0.1U 1 C14302 F1J1C1060001 16V 10U 1
C9715 F1H1H103A219 50V 0.01U 1 C14303 F1H1C104A071 16V 0.1U 1
C9716 F1H1C104A071 16V 0.1U 1 C14304 F1H1H332A013 50V 3300P 1
C9717 F1H1H103A219 50V 0.01U 1 C14305 F1H1C104A071 16V 0.1U 1
C9719 F1H1A105A028 10V 1U 1 C14307 F1H1C104A071 16V 0.1U 1
C9720 F1H1C104A071 16V 0.1U 1 C14312 F2A1C1210022 16V 120P 1
C9722 F1H1A105A028 10V 1U 1 C14315 F2A1A6810022 10V 680U 1
C9724 ERJ3GEY0R00V 1/10W 0 1 C14316 F1J1C1060001 16V 10U 1
C9725 F1H1A105A028 10V 1U 1
C9726 F1H1C104A071 16V 0.1U 1 D7701 B0BA03600021 DIODE 1 E.S.D.
C9730 F1H1A105A028 10V 1U 1 D7704 B0BA02100001 DIODE 1 E.S.D.
C9733 F1H1H101A004 50V 100P 1 D7705 B0AADM000003 DIODE 1 E.S.D.
C9735 F1H1H103A219 50V 0.01U 1 D7706 B0AADM000003 DIODE 1 E.S.D.
C9736 F1H1H103A219 50V 0.01U 1 D7707 B0JAMD000026 DIODE 1 E.S.D.
C9737 F4D55473A013 5.5V 0.047 1 D7708 B0BA01700031 DIODE 1 E.S.D.
C9738 F1H1H1800004 50V 18P 1 D7710 B0ACCE000003 DIODE 1 E.S.D.
C9739 F1H1H1800004 50V 18P 1 D9101 B0ADCH000007 DIODE 1 E.S.D.
C9741 F1H1C104A071 16V 0.1U 1 D9202 B0ACCK000005 DIODE 1 E.S.D.
C9742 F1H1H1800004 50V 18P 1 D9702 B0JACE000005 DIODE 1 E.S.D.
C9745 F1H1H1800004 50V 18P 1 D10101 B0ACCK000005 DIODE 1 E.S.D.
C9747 F1H1C104A071 16V 0.1U 1 D10102 B0ACCK000005 DIODE 1 E.S.D.
C9748 F1H1C104A071 16V 0.1U 1 D11101 B0EBKR000032 DIODE 1 E.S.D.
C9749 F1H1C104A071 16V 0.1U 1 D11151 B0HAGM000006 DIODE 1 E.S.D.
S-94
To Next Page
