Panasonic DMR-EZ49VEB

DMR-EZ49VEBK vol.1
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
D11152 B0BC01000014 DIODE 1 E.S.D.
D11153 B0HADV000001 DIODE 1 E.S.D. PS9701 K1KB20B00040 CONNECTOR(20P) 1
D11155 B0BC03200002 DIODE 1 E.S.D.
D11156 B0ACCK000005 DIODE 1 E.S.D. Q7702 B1ADLB000006 TRANSISTOR 1 E.S.D.
D11157 B0BA01600007 DIODE 1 E.S.D. Q7710 B1BABK000001 TRANSISTOR 1 E.S.D.
D11160 B0HADV000001 DIODE 1 E.S.D. Q9106 B1ABDF000033 TRANSISTOR 1 E.S.D.
D11270 B0JBSG000053 DIODE 1 E.S.D. Q9202 B1ABDF000026 TRANSISTOR 1 E.S.D.
D11701 B0JCMD000014 DIODE 1 E.S.D. Q9203 B1ABDF000026 TRANSISTOR 1 E.S.D.
D11702 B0JCMD000014 DIODE 1 E.S.D. Q9204 B1ABDF000026 TRANSISTOR 1 E.S.D.
D14301 B0JCMD000014 DIODE 1 E.S.D. Q9701 B1ADCF000172 TRANSISTOR 1 E.S.D.
D14302 B0JCMD000014 DIODE 1 E.S.D. Q9702 B1ABDF000026 TRANSISTOR 1 E.S.D.
Q9703 B1ABDF000026 TRANSISTOR 1 E.S.D.
 F11101 K5G202Y00006 FUSE 1 Q9704 B1ADGG000004 TRANSISTOR 1 E.S.D.
Q9705 B1ADCF000172 TRANSISTOR 1 E.S.D.
IC9301 C0DBGHD00011 IC 1 E.S.D Q9706 B1ABDF000026 TRANSISTOR 1 E.S.D.
IC9700 B3ZAZ0000016 IC 1 E.S.D Q10101 B1ABDF000033 TRANSISTOR 1 E.S.D.
IC9701 C2CBYY000846 IC 1 E.S.D.  Q10102 B3PBA0000454 TRANSISTOR 1 E.S.D.
IC9702 C0EBE0000194 IC 1 E.S.D.  Q11200 B3PBA0000454 TRANSISTOR 1 E.S.D.
IC9703 C0EBK0000206 IC 1 E.S.D. Q11270 B1CHQD000010 TRANSISTOR 1 E.S.D.
IC9705 RFKFM4016K IC 1 EZ49VEBK E.S.D. Q11700 B1DHDD000022 TRANSISTOR 1 E.S.D.
IC9705 RFKFM4016KT IC 1 EZ49VECK.EZ49VEGK/S E.S.D. Q14301 B1DHDD000022 TRANSISTOR 1 E.S.D.
IC9706 C0EBE0000457 IC 1 E.S.D. Q14302 B1CFRD000023 TRANSISTOR 1 E.S.D.
IC9708 C0DBGYY00700 IC 1 E.S.D.
IC11150 C0DACZH00017 IC 1 E.S.D QR7701 B1GBCFLL0043 TRANSISTOR 1 E.S.D.
IC11201 C0DBZMC00006 IC 1 E.S.D. QR9101 B1GBCFEN0015 TRANSISTOR 1 E.S.D.
IC11370 C0DAEYH00002 IC 1 E.S.D QR9703 B1GBCFNA0030 TRANSISTOR 1 E.S.D.
IC11700 C0DBAZZ00132 IC 1 E.S.D QR9705 B1GBCFNN0043 TRANSISTOR 1 E.S.D.
IC11750 C0DBEYG00002 IC 1 E.S.D QR9706 B1GBCFNN0043 TRANSISTOR 1 E.S.D.
IC14301 C0DBAYY00624 IC 1 E.S.D QR10103 B1GBCFNN0041 TRANSISTOR 1 E.S.D.
QR11200 B1GBCFNN0041 TRANSISTOR 1 E.S.D.
 IP7701 K5H751Z00003 IC PROTECTOR 1 QR11270 B1GBCFNN0041 TRANSISTOR 1 E.S.D.
 IP9102 ERBSE0R50U IC 1 QR11700 B1GBCFNN0041 TRANSISTOR 1 E.S.D.
QR11701 B1GBCFNN0041 TRANSISTOR 1 E.S.D.
K9703 ERJ3GEY0R00V 1/10W 0 1
K9704 ERJ3GEY0R00V 1/10W 0 1 R7701 ERJ3GEYJ562V 1/10W 5.6K 1
R7702 ERJ3GEYJ470V 1/10W 47 1
L7701 G0C390JA0055 COIL 39UH 1 R7703 ERJ3GEYJ473V 1/10W 47K 1
L9105 G0C680JA0019 COIL 68UH 1 R7704 ERDS2TJ271T 1/4W 270 1
L9701 G0C100K00043 COIL 10UH 1 R7710 ERJ3GEYJ332V 1/10W 3.3K 1
L9703 G0C100K00043 COIL 10UH 1 R7711 ERJ3GEYJ332V 1/10W 3.3K 1
 L11120 G0B233D00005 COIL 1 R7761 ERJ3GEYJ473V 1/10W 47K 1
 L11121 G0B233D00005 COIL 1 R9103 ERJ3GEYJ223V 1/10W 22K 1
L11270 G0A100H00025 COIL 10UH 1 R9132 ERJ3GEYJ220V 1/10W 22 1
L11701 G0A100ZA0045 COIL 1 R9143 ERJ3RBD432V 1/16W 4.3K 1
L11702 G0C100K00043 COIL 10UH 1 R9144 ERJ3RBD912V 1/16W 9.1K 1
L11703 G0C100K00043 COIL 10UH 1 R9201 ERJ3GEYJ221V 1/10W 220 1
L14301 G0C100K00043 COIL 10UH 1 R9205 ERJ3GEYJ223V 1/10W 22K 1
L14302 G0A100ZA0045 COIL 1 R9207 ERJ3GEYJ153V 1/10W 15K 1
L14303 G0C100K00043 COIL 10UH 1 R9208 ERJ3GEYJ104V 1/10W 100K 1
R9209 ERJ3GEYJ104V 1/10W 100K 1
LB9700 J0JCC0000103 COIL 1 R9210 ERJ3GEYJ224V 1/10W 220K 1
LB9701 J0JHC0000032 COIL 1 R9211 ERJ3GEYJ225V 1/10W 2.2M 1
LB9702 J0JCC0000103 COIL 1 R9212 ERJ3GEYJ273V 1/10W 27K 1
LB9703 J0JCC0000103 COIL 1 R9213 ERJ3GEYJ473V 1/10W 47K 1
LB9704 J0JKB0000012 COIL 1 R9214 ERJ3GEYJ472V 1/10W 4.7K 1
LB9705 J0JYC0000070 COIL 1 R9310 ERJ3GEYJ473V 1/10W 47K 1
LB9706 J0JYC0000070 COIL 1 R9311 ERJ3GEYJ473V 1/10W 47K 1
LB9707 J0JCC0000103 COIL 1 R9312 ERJ3GEYJ821V 1/10W 820 1
LB9711 J0JKB0000012 COIL 1 R9313 ERJ3GEYJ821V 1/10W 820 1
LB9712 J0JKB0000012 COIL 1 R9314 ERJ3GEYJ821V 1/10W 820 1
LB9713 J0JCC0000103 COIL 1 R9315 ERJ3GEYJ821V 1/10W 820 1
LB9714 J0JCC0000103 COIL 1 R9701 ERJ3GEYJ103V 1/10W 10K 1
LB9718 J0JHC0000045 COIL 1 R9702 ERJ3GEYJ103V 1/10W 10K 1
LB9720 J0JDC0000092 COIL 1 R9703 ERJ3GEYJ101V 1/10W 100 1
LB11124 J0JHC0000048 COIL 1 R9704 ERJ3GEYJ102V 1/10W 1K 1
LB11150 ERJ6GEY0R00V 1/8W 0 1 R9705 ERJ3GEYJ101V 1/10W 100 1
LB11701 J0JHC0000048 COIL 1 R9706 ERJ3GEYF562V 1/10W 5.6K 1
LB14301 ERJ6GEY0R00V 1/8W 0 1 R9707 ERJ3GEYJ101V 1/10W 100 1
R9708 ERJ3GEYJ102V 1/10W 1K 1
P9101 K1KA19A00007 CONNECTOR(19P) 1 R9709 ERJ3GEYJ472V 1/10W 4.7K 1
P9102 K1KA19A00007 CONNECTOR(19P) 1 R9710 ERJ3RBD333V 1/16W 33K 1
P9103 K1KY23AA0606 CONNECTOR(23P) 1 R9711 ERJ3GEYJ474V 1/10W 470K 1
P9104 K1KA13A00074 CONNECTOR(13P) 1 R9712 ERJ3GEYJ153V 1/10W 15K 1
P9701 K1KA03AA0301 CONNECTOR(3P) 1 R9713 ERJ3GEYJ101V 1/10W 100 1
P9703 K1KA88A00003 CONNECTOR(88P) 1 R9714 ERJ3GEYJ101V 1/10W 100 1
P9705 K1KA06AA0188 CONNECTOR(6P) 1 R9715 ERJ3GEYJ101V 1/10W 100 1
 P11101 K2AA2B000017 AC INLET 1 R9716 ERJ3GEYJ101V 1/10W 100 1
S-95
