064 Lift Motor
(1st Paper Tray)
When SPC PCB CN706-2 signal
level changes to 0V from +24V,
motor rotates in the ascending
direction.
065 OPC Clutch When SPC PCB CN728-2 signal
level changes to 0V from +24V,
clutch operates.
1 minute
066-
069
Not Used
070 Paper Feed Roller Clutch
(2nd Paper Tray)
When CST2 PCB CN773-2 signal
level changes to 0V from +24V,
clutch operates.
1 minute
071 Lift Motor
(2nd Paper Tray)
When CST2 PCB CN774-2 signal
level changes to 0V from +24V,
motor rotates in the ascending
direction.
072 Intermediate Roller Clutch
(2nd Paper Tray)
When CST2 PCB CN773-4 signal
level changes to 0V from +24V,
clutch operates.
1 minute
073-
074
Not Used
075 Paper Feed Motor
(3rd Paper Tray)
When CST3 PCB CN805-4 signal
level changes to 0V from +5V,
activate the Motor.
076 Paper Feed Roller Clutch
(3rd Paper Tray)
When CST3 PCB CN806-2 signal
level changes to 0V from +24V,
clutch operates.
1 minute
077 Lift Motor
(3rd Paper Tray)
When CST3 PCB CN804-2 signal
level changes to 0V from +24V,
motor rotates in the ascending
direction.
078 Intermediate Roller Clutch
(3rd Paper Tray)
When CST3 PCB CN806-4 signal
level changes to 0V from +24V,
clutch operates.
1 minute
079 Not Used
080 Paper Feed Roller Clutch
(4th Paper Tray)
When CST2 PCB CN773-2 signal
level changes to 0V from +24V,
clutch operates.
1 minute
081 Lift Motor
(4th Paper Tray)
When CST2 PCB CN774-2 signal
level changes to 0V from +24V,
motor rotates in the ascending
direction.
082 Intermediate Roller Clutch
(4th Paper Tray)
When CST2 PCB CN773-4 signal
level changes to 0V from +24V,
clutch operates.
1 minute
083-
084
Not Used
085 Paper Feed Roller Clutch
(Sheet Bypass)
When SPC PCB CN715-6 signal
level changes to 0V from +24V,
clutch operates.
1 minute
086 Not Used
F4 Mode (Output Check)
No. Item Function Remark
