Step 3: Please make sure the jumper pins on Tx-2 and Rx-2.
Step 4: The inverter needs to connect the power, either choices
PV, Battery or Grid. Then use the application software setting your
parameters.
Configuring the Hardware
US B po r t
Tx-1
Rx-1
Tx-2
Rx-2
Tx-1
Rx-1
Tx-2
Rx-2
UBS port
