SOLAR DC INPUT
Maximum Power 3250 W per MPPT channel / 6500 W total
Operation / MPPT Voltage Range 120 to 500VDC / 250 to 430VDC
Minimum Start Voltage 150VDC
Maximum Input Current 13A / 13A (two string input)
AC OUTPUT TO LOAD
Output Power (Continuous) @ 25°C 5500W
Overload 40/5/1sec @ 25°C 5500/6500/7500W
Rated Output Current 23 A ( @120V and 240 V)
Output Frequency (Selectable) 50/60Hz
Output Voltage L-N: 120V ± 3%; L-L: 240V ± 3%
Total harmonic distortion (THD) at rated power < 5%
Power Factor >99%
AC INPUT FROM GRID (GRID SUPPORT)
AC Input Voltage Limits (Bypass) L-L: 180 to 280V (240 V nominal)
Automatic Transfer Relay Rating / Typical Transfer Time
48A / 20ms
AC Input Frequency Range (Bypass) 55 to 65 Hz
AC OUTPUT TO GRID
Output Power (Continuous) @ 25°C 5000W
Grid Sell Current Range ( Depending On Operation Mode)
0 to 24A (@Low Grid, 211V)
Grid Sell Voltage Range L-L: 211 to 264V ± 3.0V
Grid Sell Frequency Range 59.4 to 60.4Hz ± 0.05Hz
EFFICIENCY
Peak PV to Grid 96%
CEC weighted PV to Grid 95.5%
21. SPECIFICATIONS
Specifications
DC-Coupled System
