95 Installation Manual
VOLTAGE CURRENT FREQUENCY TIME
2% 5% 2% 0.1 Sec
VOLTAGE
ZONE
ZONE LIMITS TRIP TIME DESCRIPTION
HV2 V ≥ 120% 0.166 sec Trip time when the voltage is above 288Vac
HV1
110% < V < 120%
88% ≤ V ≤ 110%
13 sec
-
Trip time when the voltage range is between
264Vac and 288Vac
No applicable when the voltage range is between
211.2Vac and 264Vac
Nominal
LV1 70% ≤ V < 88% 21 sec
Trip time when the voltage range is between
168Vac and 211.2Vac
LV2 50% ≤ V < 70% 11 sec
Trip time when the voltage range is between
120Vac and 168Vac
LV3 V < 50% 1.5 sec Trip time when the voltage is below 120Vac
PARAMETER RATING DESCRIPTION
VDC
,op 120-500V Max input voltage
VDC
,mppt
250-
430V
Maximum power
point track range
VDC
,start 150V Min start voltage
IDC
,max 13A/13A
DC input current
rating for each
string
PARAMETER RATING DESCRIPTION
Vnom
,L-N 120V
Nominal Voltage
L-N (if neutral
available)
Vnom
,L-L 240V
Nominal Voltage
L-L
P
nom 5kW
Active Power
Output
IAC
,nom 21A
Nominal current
per phase
IAC
,max 21A
Max current at
lowest operating
voltage
22. GRID SUPPORT PARAMETERS (UL1741SA)
Manufacturer Stated Tolerances
Solar DC Input
Voltage Ride-Through
Inverter AC Output
Grid Support Parameters
