96 Installation Manual
POWER
MIN INDUCTIVE,
PFMIN,IND
MIN CAPACITIVE
PFMIN,CAP
SETTLING
TIME
DESCRIPTION
5kW 70% 70% 3 Sec
Capacitive (Var production) and Induc-
tive] (Var absorption) minimum power
factor. Default PF = 1.0
PARAMETER RATING DESCRIPTION
S
rated 5 KVA Apparent Power Rating (VA)
P
rated 3.5 KW Output Power Rating (W)
V
nom 240V Nominal AC EPS voltage (V)
V
min -Vmax 211 - 264V AC EPS voltage range with function enabled (V)
VA
percent 5% Reactive Power Accuracy
VA
ramp 500 VA/sec Maximum ramp rate
Q
over-cap,max 3.57 VA
Maximum Rated Reactive Power Production (Capacitive,
Overexcited)
Q
under-ind,max 3.57 VA
Maximum Rated Reactive Power Absorption (Inductive,
Underexcited)
VA
slope,max 148 VA/V Maximum slope of power over voltage
D
min - Dmax 235 - 240V Deadband range (V)
Frequency Ride-Through
Power Factor
Volt-VAr Q(V)
FREQUENCY
ZONE
ZONE LIMITS (Hz) TRIP TIME DESCRIPTION
HF2 F ≥ 62 0.166 sec Trip time when the frequency is above 62Hz
HF1
60.5 < F < 62
58.5 ≤ F ≤ 60.5
300 sec
-
Trip time when the frequency range is between
60.5Hz and 62Hz
Not applicable when the frequency range is
between 58.5Hz and 60.5Hz
Nominal
LF1 57 ≤ F < 58.5 300 sec
Trip time when the frequency range is between
57Hz and 58Hz
LF2 F < 57 0.166 sec Trip time when the frequency is below 57Hz
Grid Support Parameters
