93 Installation Manual
DC BATTERY CHARGER
Maximum Charge Current 60A
Output Voltage Range 43 to 58V (48V Nominal)
Compatible Battery Types Li-ion
Battery Bank Range 10 to 33 kWh
GENERAL SPECIFICATIONS
Product weight 335 to 1000 lbs
Product dimensions (H x W x D) 24.2" x 42.5" x 10" (Per enclosure)
IP degree of protection NEMA Type 1/IP20
Temperature
Operating: -20 to 55°C (0°C Min Startup Temp. &
power derated above 40°C )
Storage: -25 to 70°C (-13 to 158°F)
Compliances
STANDARD COMPLIANCE
Safety UL9540, UL1973, UL1741SA, CSA 22.2
Grid Connection Standards IEEE 1547A, IEEE 1547.1
Emissions FCC part15 class B
Standards Rule 21, HECO
Specifications
AC OUTPUT TO LOAD WITH GRID ABSENT WITH GRID PRESENT
Output Power (Continuous)
@ 25°C
5500W 7000W
Overload 40/20/5/1sec @
25°C & 240V
5500/--/6500/7500W --/9600/--/--W
Overload 40/5/1sec @
25°C & 120V
2750/3250/3750W --
Rated Output Current (RMS) 23A (120V and 240V) 29A (@120V and 240V)
Output Frequency (Selectable) 50/60Hz
Output Voltage and Accuracy L-N: 120V ± 3%; L-L: 240V ± 3%
Output Voltage Limits L-L: 180 to 280V (240V Nominal)
Total harmonic distortion
(THD) at rated power
< 5%
Power Factor >99%
AC-Coupled System
