82 Installation Manual
Generator (Optional)
Step 4. Connect the control wire.
UNIT CONDITION 12VDC SOURCE DRY CONTACT
Power Off
Unit is off and no
output is powered.
0 Vdc Open
Step 3. Connect the power wire.
