FPΣ (Sigma) Expansion Units – Right Side Expansion
Wide variety of expansion units
5
Transistor output type
Digital I/O Units
Relay output type Input only type
FP0-E16RSA FP0-E8XA FP0-E16XAFP0-E8RSA
FP0-E8YRSA
8 points
Input
8 points
16 points
Input
16 points
8 points
Input
4 points
Option:
Output 8 points
Output
4 points
16 points
Input
8 points
Output
8 points
FP0-E8YPA (PNP)
FP0-E8YTA (NPN)
FP0-E16YPA (PNP)
FP0-E16YTA (NPN)
FP0-E16PA (PNP)
FP0-E16TA (NPN)
8 points
Output
8 points
16 points
Input
8 points
Output
8 points
16 points
Output
16 points
A maximum of 3 FP0 expansion units can be added to the CPU unit.
Analogue I/O Units Temperature Control Units
4 points3 points
Output
4 points
FP0-A04I
4 points
Output
4 points
FP0-A04V FP0-A80A
8 points
Input
8 points
• Input (12 bit):
± 10V, 0 – 5V,
0 – 20mA
• Output (12 bit):
± 10V, 0 – 20mA
FP0-A21A
AC Power Supply
FP0-PSA2
Input
85 to 265VAC
Terminal type
Output
24VDC/0.7A
FP0-E32RS
32 points
Input
16 points
Output
16 points
Input
2 points
Output
1 point
4 points
Input
4 points
FP0-TC4
8 points
Input
8 points
FP0-TC8
6 points
Input
6 points
FP0-RTD6
–
–
4 – 20mA
–
–
± 10V
± 10V, ± 100mV
0 – 5V, 0 – 20mA
• K, J, T, R type thermocouples
can be used
• Resolution: 0.1°C
• Accuracy: 0.8°C (R type: 3°C)
• Temperature range:
-100 to 1500°C
• Pt100, Pt1000,
Ni1000
• Temperature range:
-200 to 500°C
MEWNET-F
FP0-IOL
(MEWNET-F Slave)
PROFIBUS
FP0-DPS2
(DP Slave)
Ethernet
FPWEB
(Web-Server Unit)
Networking Units
FP0-E32PA (PNP)
FP0-E32TA (NPN)
32 points
Input
16 points
Output
16 points
