8-10
8.3.2 Setting Method
Setting with FPWIN GR
1. Select "Online" > "Online Edit Mode" in the menu bar, and press the CTRL and F2 keys.
The screen is switched to "Online Monitor".
2. Select "Tool" > "Set PLC Password" in the menu bar.
The "Set PLC Password" dialog box is displayed.
3. Set the items in the table below, and click on the “Settings” button.
Item Settings
Digit number Select "8 digits".
Operation Mode Select “Protect”.
8 digits password Enter a 8-digit password.
Setting of FP memory loader option
Check the box of the function to use.
- Limited distribution function
"Allow the download in case of same password"
- Enable the upload protection setting.
"Set that PLC cannot be uploaded"
Note:
This function is available only when a 8-digit password has been set.
To Next Page
