Panasonic FP-X0 L40MR - Page 206

Item
Number of points and range of memory
area available for use
Function
L14/L30
L40/L60
Control instruction point
Master control
relay points
(MCR) (MC)
L14/L30: 32 points
L40/L60: 256 points
No. of labels
(JP+LOOP)
(LBL)
L14/L30: 100 points
L40/L60: 256 points
No. of step
ladders (SSTP)
L14/L30: 128 stages
L40/L60: 1000 stages
No. of
subroutines
(SUB)
L14/L30: 100 subroutines
L40/L60: 500 subroutines
No. of interrupt
programs (INT)
9 programs (External input: 8 points, Periodical program: 1 point)
Constant
Decimal
constants (K)
K-32, 768 to K32, 767 (for 16-bit operation)
K-2, 147, 483, 648 to K2, 147, 483, 647
(for 32-bit operation)
Hexadecimal
constants (H)
H0 to HFFFF
(for 16-bit operation)
H0 to HFFFFFFFF
(for 32-bit operation)
Floating point
type (f)
f-1.175494 x 10
-38
to f-3.402823 x 10
38
f 1.175494 x 10
-38
to f 3.402823 x 10
38
Note1) The number of points noted above is the number reserved as the calculation memory. The actual
number of points available for use is determined by the hardware configuration.
Note2) There are two types, one is the hold type that the last state is stored even if the power supply
turns off or the mode is changed to PROG. mode from RUN mode, and the other is the non-hold
type that the state is reset.
For L14/L30 type: The hold type and non-hold type areas are fixed. For information on the
sections of each area, refer to the performance specifications.
For L40/L60 type: The sections of the hold type and non-hold type areas can be changed by the
system registers.
Note3) The points for the timer and counter can be changed by the setting of system register 5. The
numbers given in the table are the numbers when system register 5 is at its default setting.
