Panasonic FP-X0 L40MR - Page 268

Num-
ber
Name Boolean
Ope-
rand
Description
Steps
FP0/FP-e
FP0R
FP
Σ
FP-X
FP-X0
FP2
FP2SH/FP10SH
F286
P286
Upper and
lower limit
control
(32-bit data)
DLIMT
PDLIMT
S1, S2,
S3, D
When (S1+1, S1)>(S3+1, S3), (S1+1,
S1)→(D+1, D)
When (S2+1, S2)<(S3+1, S3), (S2+1,
S2)→(D+1, D)
When (S1+1, S1)<or = (S3+1, S3)<or
= (S2+1, S2), (S3+1, S3)
→
(D+1, D)
16 *1
F287
P287
Deadband
control
(16-bit data)
BAND
PBAND
S1, S2,
S3, D
When S1>S3, S3−S1→D
When S2<S3, S3−S2→D
When S1<or = S3<or = S2, 0
→
D
10 *1
F288
P288
Deadband
control
(32-bit data)
DBAND
PDBAND
S1, S2,
S3, D
When (S1+1, S1)>(S3+1, S3), (S3+1,
S3)−(S1+1, S1)→(D+1, D)
When (S2+1, S2)<(S3+1, S3), (S3+1,
S3)−(S2+1, S2)→(D+1, D)
When (S1+1, S1)<or = (S3+1, S3)<or
= (S2+1, S2),0→(D+1, D)
16 *1
F289
P289
Zone control
(16-bit data)
ZONE
PZONE
S1, S2,
S3, D
When S3<0, S3+S1→D
When S3=0, 0→D
When S3>0, S3+S2→D
10 *1
F290
P290
Zone control
(32-bit data)
DZONE
PDZONE
S1, S2,
S3, D
When (S3+1, S3)<0, (S3+1,
S3)+(S1+1, S1)→(D+1, D)
When (S3+1, S3)=0, 0→(D+1, D)
When (S3+1, S3)>0, (S3+1,
S3)+(S2+1, S2)→(D+1, D)
16 *1
BCD type real number operation instructions
F300
P300
BCD type sine
operation
BSIN
PBSIN
S, D
SIN(S1+1, S1)→(D+1, D)
6
F301
P301
BCD type
cosine
operation
BCOS
PBCOS
S, D
COS(S1+1, S1)→(D+1, D)
6
F302
P302
BCD type
tangent
operation
BTAN
PBTAN
S, D
TAN(S1+1, S1)→(D+1, D)
6
F303
P303
BCD type
arcsine
operation
BASIN
PBASIN
S, D
SIN
-1
(S1+1, S1)→(D+1, D)
6
F304
P304
BCD type
arccosine
operation
BACOS
PBACOS
S, D
COS
-1
(S1+1, S1)→(D+1, D)
6
F305
P305
BCD type
arctangent
operation
BATAN
PBATAN
S, D TAN
-1
(S1+1, S1)→(D+1, D)
6
Floating-point type real number operation instructions
F309
P309
Floating-point
type data move
FMV
PFMV
S, D
(S+1, S)→(D+1, D)
8
*2
F310
P310
Floating-point
type data
addition
F+
PF+
S1, S2,
D
(S1+1, S1)+(S2+1, S2)→(D+1, D)
14
*2
F311
P311
Floating-point
type data
subtraction
F-
PF-
S1, S2,
D
(S1+1, S1)−(S2+1, S2)→(D+1, D)
14
*2
F312
P312
Floating-point
type data
multiplication
F*
PF*
S1, S2,
D
(S1+1, S1)×(S2+1, S2)→(D+1, D)
14
*2
F313
P313
Floating-point
type data
division
F%
PF%
S1, S2,
D
(S1+1, S1)÷(S2+1, S2)→(D+1, D)
14
*2
: Available, : Not available, : Not available partially
*1) This instruction is only available for FP-e Ver.1.2 or later.
*2) This instruction is available for FP-e Ver.1.21 or later, and FP0 V2.1 or later.
