Panasonic FP-X0 L40MR - AFPX-E30 P; AFPX-E30 TD; AFPX-E30 PD

AFPX-E30P
AFPX-E30TD
AFPX-E30PD
Input terminal:
Each COM terminal in the same terminal block is connected within the unit.
Output terminal:
Each COM terminal(CO, C1 …) of Ry type is separate.
Each power supply terminal of Tr type is separate. Use them in the range surrounded by the bold black
lines.
