4.4.3 I/O Allocation of FP0/FP0R Expansion Unit
I/O do not need to be set as I/O allocation is performed automatically when an expansion unit is added.
The I/O allocation of expansion unit is determined by the installation location.
I/O numbers (when installed as the first expansion unit)
Carry the digit of hundreds place one by one since the second expansion unit.
Type of unit
Number of
allocation
Expansion
unit 1
Expansion
unit 2
Expansion
unit 3
FP0/FP0R
Expansion unit
E8X Input (8 points) X300 to X307 X320 to X327 X340 to X347
E8R
Input (4 points) X300 to X303 X320 to X323 X340 to X343
Output (4 points) Y300 to Y303 Y320 to Y323 Y340 to Y343
E8YT/P
E8YR
Output (8 points) Y300 to Y307 Y320 to Y327 Y340 to Y347
E16X Input (16 points) X300 to X30F X320 to X32F X340 to X34F
E16R
E16T/P
Input (8 points) X300 to X307 X320 to X327 X340 to X347
Output (8 points) Y300 to Y307 Y320 to Y327 Y340 to Y347
E16YT/P Output (16 points) Y300 to Y30F Y320 to Y32F Y340 to Y34F
E32T/P
Input (16 points) X300 to X30F X320 to X32F X340 to X34F
Output (16 points) Y300 to Y30F Y320 to Y32F Y340 to Y34F
FP0 analog I/O
unit
FP0-A21
Input (16 points)
CH0
WX30
(X300 to X30F)
WX32
(X320 to X32F)
WX34
(X340 to X34F)
Input (16 points)
CH1
WX31
(X310 to X31F)
WX33
(X330 to X33F)
WX35
(X350 to X35F)
Output (16 points)
WY30
(Y300 to Y30F)
WY32
(Y320 to Y32F)
WY34
(Y340 to Y34F)
FP0 A/D
conversion unit
FP0 thermo-
couple unit
FP0-A80
FP0-TC4
FP0-TC8
Input (16 points)
CH0, 2, 4, 6
WX30
(X300 to X30F)
WX32
(X320 to X32F)
WX34
(X340 to X34F)
Input (16 points)
CH1, 3, 5, 7
WX31
(X310 to X31F)
WX33
(X330 to X33F)
WX35
(X350 to X35F)
FP0 D/A
conversion unit
FP0-A04V
FP0-A04I
Input (16 points)
WX30
(X300 to X30F)
WX32
(X320 to X32F)
WX34
(X340 to X34F)
Output (16 points)
CH0, 2
WY30
(Y300 to Y30F)
WY32
(Y320 to Y32F)
WY34
(Y340 to Y34F)
Output (16 points)
CH1, 3
WY31
(Y310 to Y31F)
WY33
(Y330 to Y33F)
WY35
(Y350 to Y35F)
FP0
I/O link unit
FP0-IOL
Input 32 points X300 to X31F X320 to X33F X340 to X35F
Output 32 points Y300 to Y31F Y320 to Y33F Y340 to Y35F
FP0
RTD unit
FP0-RTD6
Input (16 points)
CH0, 2, 4
WX2
(X20 to X2F)
WX4
(X40 to X4F)
WX6
(X60 to X6F)
Input (16 points)
CH1, 3, 5
WX3
(X30 to X3F)
WX5
(X50 to X5F)
WX7
(X70 to X7F)
Output (16 points
WY2
(Y20 to Y2F)
WY4
(Y40 to Y4F)
WY6
(Y60 to Y6F)
• The data for each channel of FP0 A/D conversion unit (FP0-A80), FP0 thermocouple unit (FP0-
TC4/FP0-TC8), FP0 RTD unit (FP0-RTD6) and FP0 D/A conversion unit (FP0-A04V/FP0-A04I) is
converted and loaded with a user program that includes a switching flag to convert the data.
• Regarding FP0 CC-Link slave unit, please refer to the exclusive manual.
