6.8 GT21
6.8.1 General Specifications (GT21)
Item
Specifications
Rated voltage
24 V DC
Operating voltage range
21.6 to 26.4 V DC
Power consumption
4.8 W or less (200 mA or less)
Ambient temperature
0 to +50 C
Note1)
Ambient humidity
20 to 85% RH (at 25 C), non-condensing
Storage temperature
-20 to +60 C
Storage humidity
10 to 85% RH (at 25 C), non-condensing
Breakdown voltage
Between [power supply terminals] and [case]
500 V AC for 1 minute, Cutoff current 10mA (at default setting)
Insulation resistance
Between [power supply terminals] and [case]
100 M or more, 500 V DC, measured with megohmmeter (at default
setting)
Vibration resistance
10 to 55 Hz (1-minute cycle)
Amplitude: 0.75 mm,
10 min on 3 axes
Shock resistance
98 m/s
2
or more,
4 times on 3 axes
EC Directive applicable
EMC Directive: EN61000-6-2, EN61000-6-4
Noise immunity
1000 V [P-P] or more, Pulse width 50 ns, 1s between power supply
terminals (based on in-house measurements)
Note2)
Protective construction
IP65 (Initial value, evaluated by us)
Dustproof and drip-proof from front panel only (packing used on panel
contact surface)
Note3)
Weight
Approx. 230 g
Note1) When it is installed in a horizontal orientation (installed to make the liquid crystal face be topside)
or when the FP programmer II or C-NET adapter is connected to the TOOL port, the usable
range is 0 to +45 C.
Note2) When using our exclusive cable.
Note3) When reattaching, replace waterproof packing.
