Panasonic GT32

To Next Page

To Previous Page

7-6

7.1.5 GT03T-E

Installation dimensions

(60)

connector

Panel cutout dimensions

87.5

＋1

76.5

＋1

(Unit: mm)

Applicable panel thickness: 1.0 to 5.0 mm
