63
VQT1T90
A graph with brightness as horizontal axis and number of pixels at that brightness as vertical axis is
displayed. It is possible to determine the exposure of the whole image by looking at the distribution in
the graph.
Adjust the brightness using [IRIS]. ( 68)
Set the AUTO/MANUAL switch to MANUAL. ( 58)
Select the menu. ( 22)
[OFF]:
Not display
[ANYTIME]:
Constantly display
[ON ADJUST]:
Display only when [IRIS] is adjusted. ( 68)
This function’s default setting is [ON ADJUST].
# Example of the display
Normal
! Dark
" Bright
When the histogram display is set to
[ANYTIME] or [ON ADJUST], histogram is
displayed while adjusting [IRIS] even if
[DISPLAY] is set to [OFF].
Histogram
[ADVANCED] [HISTOGRAM] desired
setting
