VQT3A10 9
13 Audio-video output terminal [A/V] (l 36)
≥ Use the AV cable (only the supplied cable).
14 Speaker
15 USB terminal [ ] (l 11, 44, 46, 52)
16 USB terminal cover (l 11)
17 LED light (l 23)
18 Lens
19 Internal microphones
20 Card/battery door (l 10, 16)
21 Battery slot (l 10)
22 Card slot (l 16)
23 Battery release lever [BATT] (l 10)
24 Tripod receptacle
A/V
13
1514 16
20 21 22 23 24
17 18 19
