22 VQT3M88
SETUP
Rear
Photo shooting button
Power button
[@] button
[O] button
SET button
LCD monitor
HX-DC1
REC/ button
terminal cover
Battery cover
Zoom switch*
Video recording button
MENU button
button
Photo shooting button
[@] button
[O] button
SET button
REC/ button
Video recording button
MENU button
ZOOM RANGE
button
HX-DC10
Zoom switch*
Hand strap eyelet
(page 52)
HDMI terminal
USB/AV terminal
k Operation pad
* During recording: zoom photography [W/T] (page 57)
During playback: volume adjustment (page 60 and 70), image
magnification (page 67), playback display switching (page 66)
