Accessories (included): Ferrite core ´ 1
User-supplied (not included): RJ45 or BNC connectors
CAUTION
Connect these optional service cards
to the trunk through an NT1; do not connect to the U interface of the
trunk directly.
Notice
When connecting the RJ45 connector, attach the included ferrite core.
Note
• In some countries/areas, the PRI30 card must not be connected to the Public Switched Telephone
Network.
• Use only 1 type of connector (RJ45 or BNC) for connection of PRI30 card; RJ45 and BNC cannot be
used simultaneously. Set the termination switch to 120 W (default) or 75 W for connector type to be
used.
Getting Started 15
2.4 Installing the Trunk Cards
