Panasonic KX-TDE100

Programming
Number
Programming Group Title Description
[3XX]
TRS/ARS Programming TRS and Automatic Route Selection (ARS)
programming
[4XX]
CO Line Programming CO line and trunk group settings
[5XX]
COS Programming Class of Service parameters
[6XX]
Extension Programming Extension feature settings
[7XX]
Resource/Interface
Programming
PBX interface and external device settings
[8XX]
SMDR & Maintenance
Programming
Station Message Detail Recording (SMDR) and
maintenance feature settings
[9XX]
Card Programming Used to display the cards currently installed in the
PBX, or to delete a card from system programming
before physically removing it.
2.1.2 Maximum Values
Throughout this manual, maximum entry values are shown for each programming item, as shown in the
example below.
These values vary by PBX model
Disable/
Enable
SELECT
[351]
Carrier Table No. Trunk Group No.
END
ENTER ENTER
SELECT
KX-TDE100: 01–10
KX-TDE200: 01–10
KX-TDE600: 01–48
KX-TDE100: 01–64
KX-TDE200: 01–64
KX-TDE600: 01–96
However, please note that slot and port entry values are not listed within each programming item. These values
vary depending on the model of PBX and the card type installed, as shown below.
Available Slot Entry Values
KX-TDE100/KX-TDE200
PBX Model
Free Slot Number Supported Cards
KX-TDE100 01–06
All cards
KX-TDE200 01–11
Enter slot numbers as two-digit numbers (e.g. "04" for slot 4).
16 PT Programming Manual Document Version 2009-12
