Panasonic KX-TG9471B - Page 31

31
KX-TG9471B/KX-TG9472B/KX-TGA939T
Cross Reference:
Check Point (Base Unit) (P.40)
YES
NO
NO
NO
NO
NO
Is the Frequency Drift OK?
Refer to Check Point...(N).
YES
Is the Sensitivity Receiver OK?
Refer to Check Point...(O).
YES
YES
Is the Timing OK?
Refer to Check Point...(P).
YES
Is the RSSI Level OK?
Refer to Check Point...(Q).
Is the Power RAMP OK?
Refer to Check Point...(R).
Replace with a new Circuit Board.
...
