Panasonic KX-UTG200

Installation and Setup
12
Connections
To a switching hub (Ethernet cable)
To a PC (Ethernet cable)
To an EHS
Optional AC adaptor
AC adaptor
Clamp
Handset
Headset
To a handset jack
(handset)
To a headset
CAUTION
Optional AC Adaptor
• Use the following AC adaptor:
– DSA-42D-48 2 480063 (P/N: 381.00398.005)
• The AC adaptor is used as the main disconnect device. Ensure that
the AC outlet is installed near the unit and is easily accessible.
When connecting a headset
• Ensure that the headset cord has slack and is not pulled tight during
use to prevent damage to the connectors.
• Cords used to connect devices to the EHS jack or headset jack must
be less than 3 m (9.8 ft) in length.
Notice
• The following headsets can be used with this unit. (Not all
operations with the headsets can be guaranteed.)
– EHS headsets/USB headsets (KX-UTG300 only)
Selected Plantronics
®
-brand headsets
Selected Jabra
®
-brand headsets
