Panasonic Lumix DC-GX880 User Manual

23
2. Getting Started/Basic Operations
• Do not leave any metal items (such as clips) near the contact areas of the power plug.
Otherwise, a fire and/or electric shocks may be caused by short-circuiting or the
resulting heat generated.
• Do not use any other USB connection cables except the supplied one.
This may cause malfunction.
• Do not use any other AC adaptors except the supplied one.
• Do not use a USB extension cable.
• The AC adaptor (supplied) and USB connection cable (supplied) are for this camera only. Do
not use them with other devices.
• Remove the battery after use.
(The battery will be exhausted if left for a long period of time after being charged.)
• The battery becomes warm after using it and during and after charging. The camera
also becomes warm during use. This is not a malfunction.
• The battery can be recharged even when it still has some charge left, but it is not
recommended that the battery charge be frequently topped up while the battery is fully
charged.
(Since characteristic swelling may occur.)
• If a problem occurs in the power outlet, such as a power outage, charging may not be
completed normally. If this happens, disconnect the USB connection cable (supplied) and
connect it again.
• When the charging lamp does not light even if you connect the camera to the AC adaptor
(supplied) or a PC, check if they are connected correctly.

Panasonic Lumix DC-GX880 Specifications

General

Megapixel	16 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Lens
Still image resolution(s)	4592x3448, 3232x2424, 2272x1704, 1824x1368, 4592x3064, 3232x2160, 2272x1520, 1824x1216, 4592x2584, 3840x2160, 1920x1080, 1824x1024, 3424x3424, 2416x2416, 1712x1712, 1712x1712
USB version	2.0
USB connector	Micro-USB B
HDMI connector type	Micro
Bluetooth	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Backlight, Children, Night portrait, Panorama, Portrait, Sports
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Playback modes	Slideshow, Zoom
Shooting modes	Aperture priority, Auto, Manual, Movie, Shutter priority
GPS (satellite)	-
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
Playback zoom (max)	16 x
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Filter size	37 mm
Digital zoom	4 x
Optical zoom	- x
Focal length range	12 - 32 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	22
Minimum aperture number	3.5
Lens 2 focal length range	35 - 100 mm
Number of diaphragm blades	7
Number of aspheric elements	3
Lens 2 maximum aperture number	4
Lens structure (elements/groups)	8/7
Maximum focal length (35mm film equiv)	64 mm
Minimum focal length (35mm film equiv)	24 mm
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	49
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance	0.2 m
Normal focusing range (tele)	- m
Product color	Black
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Battery voltage	7.2 V
Battery capacity	680 mAh
Battery life (CIPA standard)	210 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Flash modes	Auto, Forced off, Forced on, Slow synchronization
Flash sync-speed	1/50 s
Flash exposure correction	±3EV (1/3 EV step)
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video recording time	60 min
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Audio formats supported	AAC
Cables included	AC, USB
Memory slots	1
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display diagonal (metric)	7.5 cm
Display resolution (numeric)	1040000 pixels

Weight and Dimensions

Depth	33.3 mm
Width	106.5 mm
Height	64.6 mm
Weight	240 g
Lens diameter	55.5 mm
Weight (including battery)	270 g
