Panasonic Lumix DC-GX880 User Manual

3. Recording Modes
78
Taking Pictures by Specifying the Aperture/
Shutter Speed
Recording Mode:
• The effects of the set aperture value and shutter speed will not be visible on the recording
screen. To check on the recording screen, please use [Preview]. (P82)
• The brightness of the screen and the recorded pictures may differ. Check the pictures on the
playback screen.
• Rotate the control dial to display the Exposure Meter. Unsuitable areas of the range are
displayed in red.
• If the exposure is not adequate, the aperture value and the shutter speed turn red and blink
when the shutter button is pressed halfway.
(Example: In Manual
Exposure Mode)
A Exposure meter
B Aperture value
C Shutter speed
Aperture
value
Small
It becomes easier to
defocus the
background.
Large
It becomes easier to
maintain focus as far as
the background.
Shutter
speed
Slow
It becomes easier to
express movement.
Fast
It becomes easier to
freeze movement.
F
1258
5.64.0 8.0 11
603015
3030305.6
00 +3
SSSS SSSS

Panasonic Lumix DC-GX880 Specifications

General

Megapixel	16 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Lens
Still image resolution(s)	4592x3448, 3232x2424, 2272x1704, 1824x1368, 4592x3064, 3232x2160, 2272x1520, 1824x1216, 4592x2584, 3840x2160, 1920x1080, 1824x1024, 3424x3424, 2416x2416, 1712x1712, 1712x1712
USB version	2.0
USB connector	Micro-USB B
HDMI connector type	Micro
Bluetooth	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Backlight, Children, Night portrait, Panorama, Portrait, Sports
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Playback modes	Slideshow, Zoom
Shooting modes	Aperture priority, Auto, Manual, Movie, Shutter priority
GPS (satellite)	-
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
Playback zoom (max)	16 x
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Filter size	37 mm
Digital zoom	4 x
Optical zoom	- x
Focal length range	12 - 32 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	22
Minimum aperture number	3.5
Lens 2 focal length range	35 - 100 mm
Number of diaphragm blades	7
Number of aspheric elements	3
Lens 2 maximum aperture number	4
Lens structure (elements/groups)	8/7
Maximum focal length (35mm film equiv)	64 mm
Minimum focal length (35mm film equiv)	24 mm
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	49
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance	0.2 m
Normal focusing range (tele)	- m
Product color	Black
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Battery voltage	7.2 V
Battery capacity	680 mAh
Battery life (CIPA standard)	210 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Flash modes	Auto, Forced off, Forced on, Slow synchronization
Flash sync-speed	1/50 s
Flash exposure correction	±3EV (1/3 EV step)
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video recording time	60 min
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Audio formats supported	AAC
Cables included	AC, USB
Memory slots	1
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display diagonal (metric)	7.5 cm
Display resolution (numeric)	1040000 pixels

Weight and Dimensions

Depth	33.3 mm
Width	106.5 mm
Height	64.6 mm
Weight	240 g
Lens diameter	55.5 mm
Weight (including battery)	270 g
