Before Use
- 12 -
11 Camera ON/OFF switch (P21)
12 Zoom lever (P42)
13 [E.ZOOM] button (P44)
14 Speaker (P110)
15 Microphone (P77, 103, 128)
16 Shutter button (P35, 77)
17 Mode dial (P33)
18 Strap eyelet
•
Be sure to attach the strap when using
the camera to ensure that you will not
drop it.
19 Lens barrel
20 [COMPONENT OUT] socket (P141)
21 [AV OUT/DIGITAL] socket (P130, 133,
139)
22 [DC IN] socket (P130, 133)
•
Always use a genuine Panasonic AC adaptor (optional).
• This camera cannot charge the battery even when the AC adaptor (optional) is connected
to it.
23 Tripod receptacle
•
When you use a tripod, make sure the
tripod is stable when the camera is
attached to it.
24 Card/Battery door (P17)
25 Release lever (P17)
11 1312
14 15 1716
19
21
22
20
18
23 24
25
