- 11 -
Before Use
Names of the Components
1Flash (P52)
2 Lens (P5, 146)
3 Self-timer indicator (P58)
AF assist lamp (P104)
4 LCD monitor (P50, 142)
5 Status indicator (P18, 29, 35)
6 [MENU/SET] button (P21)
7 [DISPLAY] button (P50)
8 [Q.MENU] (P26)/Delete (P48) button
9 [REC]/[PLAYBACK] selector switch
(P23)
10 Cursor buttons
A: 3/Exposure compensation (P59)/
Flash output adjustment (P55)/Auto
bracket (P60)/Colour bracket (P61)
B: 4/Macro mode (P57)
AF Tracking (P37, 95)
C: 2/Self-timer button (P58)
D: 1/Flash setting button (P52)/
White balance fine adjustment (P90)
In these operating instructions, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
