Panasonic Lumix DMC-GX85 User Manual

4. Focus, Brightness (Exposure) and Color tone Settings
104
Applicable modes:
You can move the AF area displayed on the viewfinder by
touching the monitor.
•
Press the shutter button halfway to determine the focus position.
If you press [DISP.] before determining the focus position, the AF area frame returns to the
center position.
• To cancel the AF area frame when the Auto Focus Mode (P97) is set to [š] ([Face/Eye
Detection]), [ ] ([Tracking]) or [ ] ([49-Area]), press [MENU/SET].
• The Touch Shutter function (P52) is disabled when using [Touch Pad AF].
Not available in these cases:
•
The [Touch Pad AF] does not function in the following cases:
– When [4K Live Cropping] is set
– When [Pull Focus] in [Snap Movie] is set to [ON]
Setting the AF area position with the Touch Pad
> [Custom] > [Touch Settings] > [Touch Pad AF]
[EXACT]
Moves the AF area of the
Viewfinder by touching a
desired position on the Touch
Pad.
[OFFSET]
Moves the AF area of the
viewfinder according to the
distance you drag the touch
pad (P51).
[OFF] —
MENU

Panasonic Lumix DMC-GX85 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	16 megapixels
Image Processor	Venus Engine
Viewfinder Type	Electronic
Built-in Flash	Yes
External Flash	Hot Shoe
Wireless Connectivity	Wi-Fi
Dimensions	122 x 70.6 x 43.9 mm
Sensor Size	17.3 x 13.0 mm (Four Thirds)
ISO Sensitivity	200-25600 (extendable to 100-25600)
Shutter Speed	1/4000 sec - 60 sec
Continuous Shooting	Up to 8 fps
Autofocus System	Contrast Detection
Image Stabilization	5-axis in-body stabilization
Video Recording	4K UHD at 30p/24p
Viewfinder Resolution	2, 764, 800 dots
LCD Screen	3.0" tilting touchscreen, 1.04 million dots
Battery Life	Approx. 290 shots (CIPA standard)
Battery	DMW-BLG10 Lithium-Ion
Weight	426 g (with battery and memory card)
Storage Media	SD/SDHC/SDXC
