Panasonic Lumix DMC-GX85 User Manual

4. Focus, Brightness (Exposure) and Color tone Settings
106
Adjusting Focus Manually
Applicable modes:
Use this function when you want to fix the focus or when the distance between the lens
and the subject is determined and you do not want to activate Auto Focus.
1
Select the menu. (P54)
2
Press 2 ().
3
Press 3/4/2/1 to adjust the focus position, and press [MENU/SET].
• The assist screen is displayed, enlarging the area. (MF
Assist)
• You can also enlarge the area by rotating the focus ring,
moving the focus lever, or pinching out (P51) the screen
or touching the screen twice.
• You can also adjust the focus position by dragging (P51)
the screen.
• Pressing [DISP.] resets the focus position back to the center.
4
Adjust the focus.
> [Rec] > [Focus Mode]> [MF]
The operations used to focus manually differ depending on the lens.
When using an interchangeable lens (H-FS12032) with no focus ring
Press 1: Focuses on nearby subject
Press 2: Focuses on distant subjects
A Slide bar
• These operations are possible only on the focus
adjustment screen.
• Pressing and holding 2/1 will increase the
focus speed.
• Focus can also be adjusted by dragging the slide bar.
MENU
リヴヰ
ョㄏピ
AF
+
A

Panasonic Lumix DMC-GX85 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	16 megapixels
Image Processor	Venus Engine
Viewfinder Type	Electronic
Built-in Flash	Yes
External Flash	Hot Shoe
Wireless Connectivity	Wi-Fi
Dimensions	122 x 70.6 x 43.9 mm
Sensor Size	17.3 x 13.0 mm (Four Thirds)
ISO Sensitivity	200-25600 (extendable to 100-25600)
Shutter Speed	1/4000 sec - 60 sec
Continuous Shooting	Up to 8 fps
Autofocus System	Contrast Detection
Image Stabilization	5-axis in-body stabilization
Video Recording	4K UHD at 30p/24p
Viewfinder Resolution	2, 764, 800 dots
LCD Screen	3.0" tilting touchscreen, 1.04 million dots
Battery Life	Approx. 290 shots (CIPA standard)
Battery	DMW-BLG10 Lithium-Ion
Weight	426 g (with battery and memory card)
Storage Media	SD/SDHC/SDXC
