Panasonic Lumix DMC-GX85 User Manual

1. Before Use
14
Names and Functions of Components
∫ Camera body
4
14 1317 16
11
7
5
1
12
15
8 9 10
6
12
2 3
1
Camera ON/OFF switch (P35)
2
Charging lamp (P22)/
Status indicator (P35)/
Wi-Fi
®
connection lamp (P252)
3
Motion picture button (P166)
4
Shutter button (P42)
5
Mode dial (P43)
6
Front dial (P44)
7
Self-timer indicator (P137)/
AF Assist Lamp (P211)
8
Flash (P156)
9
Hot shoe (Hot shoe cover) (P307)
• Keep the Hot Shoe Cover out of reach of
children to prevent swallowing.
10
Focus distance reference mark (P108)
11
Stereo microphone (P208)
• Be careful not to cover the microphone with
your finger. Doing so may make sound
difficult to record.
12
Shoulder strap eyelet (P18)
13
Lens release button (P32)
14
Lens lock pin
15
Mount
16
Sensor
17
Lens fitting mark (P32)

Panasonic Lumix DMC-GX85 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	16 megapixels
Image Processor	Venus Engine
Viewfinder Type	Electronic
Built-in Flash	Yes
External Flash	Hot Shoe
Wireless Connectivity	Wi-Fi
Dimensions	122 x 70.6 x 43.9 mm
Sensor Size	17.3 x 13.0 mm (Four Thirds)
ISO Sensitivity	200-25600 (extendable to 100-25600)
Shutter Speed	1/4000 sec - 60 sec
Continuous Shooting	Up to 8 fps
Autofocus System	Contrast Detection
Image Stabilization	5-axis in-body stabilization
Video Recording	4K UHD at 30p/24p
Viewfinder Resolution	2, 764, 800 dots
LCD Screen	3.0" tilting touchscreen, 1.04 million dots
Battery Life	Approx. 290 shots (CIPA standard)
Battery	DMW-BLG10 Lithium-Ion
Weight	426 g (with battery and memory card)
Storage Media	SD/SDHC/SDXC
