Panasonic Lumix DMC-GX85 User Manual

215
9. Using Menu Functions
[Histogram]
This allows you to set either to display or not display the
histogram.
You can set the position by pressing 3/4/2/1.
• Direct touch operation is also possible from the recording
screen.
• A histogram is a graph that
displays brightness along the
horizontal axis (black to white)
and the number of pixels at each
brightness level on the vertical
axis.
It allows you to easily check a picture’s exposure.
A dark
B bright
• When the recorded picture and the histogram do not
match each other under the following conditions, the
histogram is displayed in orange.
– During Exposure Compensation
– When the flash is activated
– When the correct exposure is not achieved, such as
when the lighting is low.
• The histogram is an approximation in the Recording
Mode.
s
[Guide Line]
This will set the pattern of guide lines displayed when
taking a picture.
When [ ] is set, guideline positions can be set by
pressing 3/4/2/1.
• You can also set the position directly by touching [ ] on
the guideline of the recording screen.
• The guideline is not displayed in the Panorama Shot
Mode.
s
> [Custom]
MENU

Panasonic Lumix DMC-GX85 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	16 megapixels
Image Processor	Venus Engine
Viewfinder Type	Electronic
Built-in Flash	Yes
External Flash	Hot Shoe
Wireless Connectivity	Wi-Fi
Dimensions	122 x 70.6 x 43.9 mm
Sensor Size	17.3 x 13.0 mm (Four Thirds)
ISO Sensitivity	200-25600 (extendable to 100-25600)
Shutter Speed	1/4000 sec - 60 sec
Continuous Shooting	Up to 8 fps
Autofocus System	Contrast Detection
Image Stabilization	5-axis in-body stabilization
Video Recording	4K UHD at 30p/24p
Viewfinder Resolution	2, 764, 800 dots
LCD Screen	3.0" tilting touchscreen, 1.04 million dots
Battery Life	Approx. 290 shots (CIPA standard)
Battery	DMW-BLG10 Lithium-Ion
Weight	426 g (with battery and memory card)
Storage Media	SD/SDHC/SDXC
