Panasonic Lumix DMC-GX85 User Manual

33
2. Getting Started/Basic Operations
When using the interchangeable lens (H-FS12032/
H-FS35100/H-FS14140)
Rotate the zoom ring of the lens.
When recording into strong backlight, irregular reflection may occur within the lens. The
lens hood reduces the inclusion of unwanted light in the recorded images and lowers the
drop in contrast. The lens hood cuts off excess lighting and improves the picture quality.
•
The interchangeable lens (H-FS12032/H-H020A) does not have a lens hood.
To attach the lens hood (flower shape) that came with the interchangeable lenses
(H-FS35100/H-FS14140)
Hold the lens hood by placing your fingers as
shown in the figure.
•
Do not hold the lens hood in such a way that it will be
bent.
1 Align the mark A ( ) on the lens hood with the
mark on the tip of the lens.
2 Rotate the lens hood in the direction of the
arrow until it clicks and then align the mark B
( ) on the lens hood with the mark on the tip
of the lens.
Zoom operations
T side: Enlarges distant subject
W side: Widens angle of view
Attaching the Lens Hood
T
W



Panasonic Lumix DMC-GX85 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	16 megapixels
Image Processor	Venus Engine
Viewfinder Type	Electronic
Built-in Flash	Yes
External Flash	Hot Shoe
Wireless Connectivity	Wi-Fi
Dimensions	122 x 70.6 x 43.9 mm
Sensor Size	17.3 x 13.0 mm (Four Thirds)
ISO Sensitivity	200-25600 (extendable to 100-25600)
Shutter Speed	1/4000 sec - 60 sec
Continuous Shooting	Up to 8 fps
Autofocus System	Contrast Detection
Image Stabilization	5-axis in-body stabilization
Video Recording	4K UHD at 30p/24p
Viewfinder Resolution	2, 764, 800 dots
LCD Screen	3.0" tilting touchscreen, 1.04 million dots
Battery Life	Approx. 290 shots (CIPA standard)
Battery	DMW-BLG10 Lithium-Ion
Weight	426 g (with battery and memory card)
Storage Media	SD/SDHC/SDXC
