48 VQT1Z93 VQT1Z93 49
Taking images with self-timer
Mode:
Taking pictures/motion pictures with exposure
compensation
Mode:
We recommend using a tripod. This is also effective for correcting jitter when pressing the
shutter button, by setting the self timer to 2 seconds.
When set to BURST, three pictures are taken. When set to the ‘FLASH BURST’ scene
mode, five pictures are taken.
Focus will be automatically adjusted immediately before recording if shutter button is
pressed fully here.
After self-timer lamp stops flashing, it may then be lit for AF assist lamp.
This function cannot be used in the ‘UNDERWATER’ and ‘HI-SPEED BURST’ scene
modes, or in (MOTION PICTURE mode) .
In some modes, only ‘2SEC.’ or only ‘10SEC.’ may be selected.
INTELLIGENT AUTO mode: ‘10SEC.’
CLIPBOARD mode, ‘SELF PORTRAIT’ scene mode: ‘2SEC.’
Self-timer indicator
(Flashes for set duration)
Display ‘SELFTIMER’
Select time duration
Displayed for approx. 5 sec.
Can also be selected with .
Take an image
Press fully the shutter button to start recording
after the preset time.
To cancel while in operation
Press ‘MENU/SET’
Corrects exposure when adequate exposure cannot be obtained (if difference between
brightness of object and background, etc.). Depending on the brightness, this may not be
possible in some cases.
EXPOSURE
Display ‘EXPOSURE’
Example of exposure compensation
Minus direction
Plus direction
Over-exposed
Optimum exposure
Under-exposed
Select a value
‘0’ (no compensation)
AUTO BRACKET (Pictures only)
Takes 3 pictures in succession, changing the exposure. After exposure compensation, the
compensation value is as standard.
Display ‘AUTO BRACKET’
e.g. AUTO BRACKET with ±1EV
First picture
0EV
(Standard)
Second picture
-1EV
(Darker)
Third picture
+1EV
(Brighter)
Press twice to switch
‘EXPOSURE’ to
‘AUTO BRACKET’.
Select a value
‘0’ (no compensation)
Value displayed after exposure compensation set
Cannot be used with flash or when there is remaining capacity for only 2 more pictures.
When ‘AUTO BRACKET’ is set, is displayed on the left of the screen.
Cancelled when the power is turned off.
When AUTO BRACKET is set, ‘MULTI ASPECT’ and ‘BURST’ are cancelled.
AUTO BRACKET cannot be set in ‘TRANSFORM’, ‘PANORAMA ASSIST’, ‘HI-SPEED
BURST’, ‘FLASH BURST’, ‘STARRY SKY’, ‘PIN HOLE’, and ‘FILM GRAIN’ scene modes.
Exposure compensation cannot be used with the ‘STARRY SKY’ scene mode.
EXPOSURE only

Table of Contents

Other manuals for Panasonic LUMIX DMC-TZ7

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-TZ7 and is the answer not in the manual?

Panasonic LUMIX DMC-TZ7 Specifications

General IconGeneral
Megapixel10.1 MP
Sensor typeCCD
Image stabilizerYes
Image sensor size1/2.33 \
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution3648 x 2736 pixels
Digital zoom4 x
Optical zoom12 x
Combined zoom48 x
Focal length range4.1 - 49.2 mm
Lens structure (elements/groups)10/8
Digital SLRNo
Focal length (35mm film equivalent)25 - 300 mm
Focus adjustmentAuto
Auto focusing (AF) modescontinuous auto focus, multi point auto focus, single auto focus, spot auto focus
Flash modesFlash off, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 3.6 m
Internal memory40 MB
Compatible memory cardsmmc, sd
Motion JPEG frame rate30 fps
Video formats supportedM-JPEG
Maximum video resolution1280 x 720 pixels
Audio systemstereo
Display diagonal3 \
Display resolution (numeric)460000 pixels
USB version2.0
Scene modesbeach, Candlelight, Children, Close-up (macro), Cuisine, Fireworks, Night portrait, party (indoor), Portrait, self-portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editingresizing, trimming
Photo effectsblack&white, Sepia, Vivid
White balanceauto, Cloudy, custom modes, daylight, Shade
Camera playbackmovie, single image, slide show, thumbnails
Self-timer delay2 s
Playback zoom (max)16 x
Product colorBrown
Battery capacity895 mAh
Battery life (CIPA standard)300 shots
Light meteringcentre-weighted, spot
Weight and Dimensions IconWeight and Dimensions
Depth32.8 mm
Width103.3 mm
Height59.6 mm
Weight229 g
