Panasonic LUMIX GH5 II User Manual

5. Focus/Zoom – Selecting the AF Mode
145
[225-Area]
The camera selects the most optimal AF area to focus from 225 areas.
When multiple AF areas are selected, all selected AF areas will be brought
into focus.
When the focus mode is set to [AFC], ensuring that the subject stays within
the 225 areas during recording will ensure the subject stays in focus.
 Specify the [AFC] Start Point
When the focus mode is set to [AFC], you can specify at which area to start
[AFC].
1 Set the focus mode to [AFC]. (Selecting the Focus Mode: 125)
2 Set [AFC Start Point (225-Area)] to [ON].
•  [ ]  [ ]  [AFC Start Point (225-Area)]  [ON]
3 Press [ ] to display the AF mode selection screen.
4 Select [ ] and then press 4.
• After performing Steps 1 and 2, the icon changes from [ ] to [ ].
5 Press 3421 to move the AF area to the start point.
• You can also move the AF area by touching.
• To return the position back to the center, press [DISP.].
6 Press .

Panasonic LUMIX GH5 II Specifications

General

Sensor Type	Live MOS
Megapixels	20.3 MP
Sensor Size	17.3 x 13.0 mm
Image Sensor Format	Four Thirds
Image Processor	Venus Engine
Viewfinder	OLED Live View Finder
Dimensions	138.5 x 98.1 x 87.4 mm
Autofocus System	Contrast Detection
Video Resolution	4K (3840 x 2160)
Viewfinder Resolution	3, 680k-dot
Screen	3.0" Free-Angle Touchscreen LCD
Screen Resolution	1, 840, 000 Dot
Image Stabilization	5-axis in-body image stabilization
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	12 fps
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 Shots
Battery	DMW-BLK22 Lithium-ion
Weight	727 g
