Panasonic LUMIX GH5 II User Manual

14. Menu Guide – [Photo] Menu
523
[Photo] menu ([Focus])
: Default settings
[AF Custom Setting(Photo)]
[AF Assist Light]
[Set 1]/[Set 2]/[Set 3]/[Set 4]
Select features of AF operation when recording using [AFC] that are appropriate for
the subject and scene.
([AF Custom Setting(Photo)]: 132)
[ON]/[OFF]
When recording in low light conditions, the AF assist light turns on when you press
the shutter button halfway, making it easier for the camera to focus.
• The effective range of the AF assist light is different depending on the lens used.
– When the interchangeable lens (H-ES12060) is attached and at wide-angle end.
Approx. 1.0 m (3.3 feet) to 3.5 m (11 feet)
– When the interchangeable lens (H-FS12060) is attached and at wide-angle end.
Approx. 1.0 m (3.3 feet) to 3.0 m (9.8 feet)
• Remove the lens hood.
• The AF assist light may be greatly blocked, and it may become harder to focus
when a lens with large diameter is used.

Panasonic LUMIX GH5 II Specifications

General

Sensor Type	Live MOS
Megapixels	20.3 MP
Sensor Size	17.3 x 13.0 mm
Image Sensor Format	Four Thirds
Image Processor	Venus Engine
Viewfinder	OLED Live View Finder
Dimensions	138.5 x 98.1 x 87.4 mm
Autofocus System	Contrast Detection
Video Resolution	4K (3840 x 2160)
Viewfinder Resolution	3, 680k-dot
Screen	3.0" Free-Angle Touchscreen LCD
Screen Resolution	1, 840, 000 Dot
Image Stabilization	5-axis in-body image stabilization
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	12 fps
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 Shots
Battery	DMW-BLK22 Lithium-ion
Weight	727 g
