Panasonic LUMIX GH5 II User Manual

10. Recording Videos – Main Assist Functions
370
[SS/Gain Operation]
You can switch the units of shutter speed values and gain (sensitivity)
values.
 [ ]  [ ]  Select [SS/Gain Operation]
[SEC/ISO] Displays the shutter speed in seconds and the gain in ISO.
[ANGLE/ISO]
Displays the shutter speed in degrees and the gain in ISO.
• The angle can be set in a range between 11° and 358°.
(When [Synchro Scan] is set to [OFF])
[SEC/dB]
Displays the shutter speed in seconds and the gain in dB.
• 0 dB is equivalent to ISO 200. (When [Photo Style] is set to
[V-Log L] or [Hybrid Log Gamma], it is equivalent to ISO 400.)
• When [SS/Gain Operation] is set to [SEC/dB], menu names change as shown
below:
– [ISO Sensitivity (video)]  [Gain Setting]
– [ISO Auto Lower Limit Setting]  [Auto Gain Lower Limit Setting]
– [ISO Auto Upper Limit Setting]  [Auto Gain Upper Limit Setting]
– [Extended ISO]  [Extended Gain Setting]
– [ISO Displayed Setting]  [Gain Displayed Setting]

Panasonic LUMIX GH5 II Specifications

General

Sensor Type	Live MOS
Megapixels	20.3 MP
Sensor Size	17.3 x 13.0 mm
Image Sensor Format	Four Thirds
Image Processor	Venus Engine
Viewfinder	OLED Live View Finder
Dimensions	138.5 x 98.1 x 87.4 mm
Autofocus System	Contrast Detection
Video Resolution	4K (3840 x 2160)
Viewfinder Resolution	3, 680k-dot
Screen	3.0" Free-Angle Touchscreen LCD
Screen Resolution	1, 840, 000 Dot
Image Stabilization	5-axis in-body image stabilization
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	12 fps
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 Shots
Battery	DMW-BLK22 Lithium-ion
Weight	727 g
