Panasonic LUMIX GH5 II User Manual

5. Focus/Zoom – Record Using MF
172
 Operations on the MF Assist Screen
*1 When using an interchangeable lens with no focus ring, you can perform these
operations after pressing 4 to display the screen that lets you set the area to be
enlarged.
• When the picture is displayed in windowed mode, you can enlarge the picture by
approx. 3k to 6k; when the picture is displayed in full screen, you can enlarge the
picture by approx. 3k to 20k.
Button
operation
Touch
operation
Description of operation
3421
*1
Drag Moves the enlarged display position.
Pinch out/
pinch in
Enlarges/reduces the screen in small steps.
— Enlarges/reduces the screen.
Switches magnification window (windowed
mode/full screen mode).
[DISP.]
*1
[Reset]
*1
First time: Returns the MF Assist position to the
center.
Second time: Returns the MF Assist
magnification to the default setting.
[AF ON] The AF operates.
• On the recording screen, you can rotate the focus ring to display the MF Assist
screen. If the focus ring has been rotated to enlarge the display, the assist screen
will be exited a short time after you cease the operation.
AF

Panasonic LUMIX GH5 II Specifications

General

Sensor Type	Live MOS
Megapixels	20.3 MP
Sensor Size	17.3 x 13.0 mm
Image Sensor Format	Four Thirds
Image Processor	Venus Engine
Viewfinder	OLED Live View Finder
Dimensions	138.5 x 98.1 x 87.4 mm
Autofocus System	Contrast Detection
Video Resolution	4K (3840 x 2160)
Viewfinder Resolution	3, 680k-dot
Screen	3.0" Free-Angle Touchscreen LCD
Screen Resolution	1, 840, 000 Dot
Image Stabilization	5-axis in-body image stabilization
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	12 fps
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 Shots
Battery	DMW-BLK22 Lithium-ion
Weight	727 g
