Panasonic LUMIX GH5 II User Manual

11. Connections with External Devices (Video) – HDMI Devices (HDMI Output)
428
 [iA]/[P]/[A]/[S]/[M] Mode
• Output is the same as [ ] mode during video recording.
• During recording standby, it is output according to the setting of [Aspect Ratio] in the
[Photo] ([Image Quality]) menu.
– When set to any [Aspect Ratio] other than 16:9, bands are added to the left and
right of the image for output.
– Resolution, frame rate, YUV, and bit value output matches the connected device.
 Notice Regarding HDMI Output
• It may take some time for the output method to change.
• When you use the HDMI output during recording, the image may be displayed with a
time lag.
• Beep sounds, AF beep, and electronic shutter sounds are muted during HDMI
output.
• When you check the image and audio from the TV connected to the camera, the
microphone of the camera may pick up the sound from the speakers of the TV,
producing an abnormal sound (audio feedback).
If this occurs, move the camera away from the TV or lower the volume on the TV.
• Certain setting screens are not output via HDMI.
• There is no output via HDMI while you are recording with the following functions:
– [6K/4K PHOTO]/[Post-Focus]
• If the temperature of the camera rises, [ ] may be displayed, recording may stop,
and some functions may become unavailable temporarily. Wait until the camera
cools down.

Panasonic LUMIX GH5 II Specifications

General

Sensor Type	Live MOS
Megapixels	20.3 MP
Sensor Size	17.3 x 13.0 mm
Image Sensor Format	Four Thirds
Image Processor	Venus Engine
Viewfinder	OLED Live View Finder
Dimensions	138.5 x 98.1 x 87.4 mm
Autofocus System	Contrast Detection
Video Resolution	4K (3840 x 2160)
Viewfinder Resolution	3, 680k-dot
Screen	3.0" Free-Angle Touchscreen LCD
Screen Resolution	1, 840, 000 Dot
Image Stabilization	5-axis in-body image stabilization
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	12 fps
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 Shots
Battery	DMW-BLK22 Lithium-ion
Weight	727 g
