Panasonic LUMIX GH5 II User Manual

11. Connections with External Devices (Video) – Headphones
442
 Switching the Sound Output Method
 [ ]  [ ]  Select [Sound Output]
 Adjusting the Headphone Volume
Connect the headphones and rotate .
: Reduces the volume.
: Increases the volume.
•
You can also adjust the volume by touching [ ]/[ ] on the playback screen.
To adjust the volume using the menu:
1 Select [Headphone Volume].
•  [ ]  [ ]  [Headphone Volume]
2 Press 34 to adjust the headphone volume and then press or .
• It can be adjusted in a range of [0] to [LEVEL15].
[REALTIME]
Audio without time lag.
It may differ from the sound recorded in videos.
[REC SOUND]
Audio to be recorded in videos.
Output sound may be delayed from actual sound.
• The setting is fixed to [REC SOUND] in the following cases:
– During output of audio via HDMI
– When [Special Mic.] is set to [LENS AUTO], [SHOTGUN], [S.SHOTGUN], or
[MANUAL]
– When using an XLR Microphone Adaptor (DMW-XLR1: optional)

Panasonic LUMIX GH5 II Specifications

General

Sensor Type	Live MOS
Megapixels	20.3 MP
Sensor Size	17.3 x 13.0 mm
Image Sensor Format	Four Thirds
Image Processor	Venus Engine
Viewfinder	OLED Live View Finder
Dimensions	138.5 x 98.1 x 87.4 mm
Autofocus System	Contrast Detection
Video Resolution	4K (3840 x 2160)
Viewfinder Resolution	3, 680k-dot
Screen	3.0" Free-Angle Touchscreen LCD
Screen Resolution	1, 840, 000 Dot
Image Stabilization	5-axis in-body image stabilization
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	12 fps
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 Shots
Battery	DMW-BLK22 Lithium-ion
Weight	727 g
