2
(Underside)
Rotating
rollers
Floor nozzle tongue
Brush holder
Care lamp (red) (P. 12)
Part Names
Clean lamp ( P. 9 )
Clip-on hook
( P. 3 )
Operation switch ( P. 8 )
Operation mode switch
( P. 8 )
Main unit
Battery status indicator
lamp (blue) (P. 7, 9)
Telescopic 2-way nozzle
( P. 1 0 )
Agitator (brush)
(Underside of the floor nozzle)
Roller
Charging adapter
(P. 6)
Plug
Check the included accessories.
Parts enclosed in are included accessories.
Stick cleaner
Non-slip Rubber
●Useful when leaning the stick
cleaner against walls.
Battery cover (P. 19)
●The battery is set inside.
Rechargeable lithium-ion battery
・Rated capacity 2350 mAh
・Number of cells 6 cells
Exhaust vent
(P. 15)
Connector
(P. 6)
Dust box
(P. 12)
Extension wand
Floor nozzle
(Power nozzle)
Cord (power cord)
* Electrical plug might be
different from illustration.
Electrical plug *
Roller
Raised fabric
Raised fabric
Dusting brush
( P. 11 )
Cleaning brush
( P. 1 3 )
Nozzle cover
Mattress nozzle
( P. 11 )
Screws
( P. 3 )
