Panasonic MC-SB85K - Setting It up

Mounting the clip-on hook
3
ENGLISH
When mounting the clip-on hook…
Let’s check this
before mounting the
clip-on hook!
2
Attach the clip-on
hook’s cover
Click
①
②
② Turn the cover, and match
the “ □” with the “ ○”
① Match the “ □” with the other “□”
Cover
Mounting height
About 102 cm
1
Mount the clip-on
hook’s base
● Confirm which section of the base faces up or down,
and screw in the screws in the order of
① , ② .
● Check that the base’s centre line is
parallel with the floor, and screw in
the screws.
Request
Base
Line
①
②
WARNING
Do not mount it on weak wall surfaces
such as the following
Do not mount it on wall surfaces such as
metal laths and stainless steel plates, etc.
(Risks of injury due to falling)
◦Gypsum board
◦ Veneer boards, etc. with a thickness of 10 mm or less
◦Lightweight aerated concrete◦Concrete blocks
(If there are electric leakages, they might cause fire)
● Select a board with a thickness of 10 mm or
more, or a place with pillars or crosspieces
on the back side, then mount it on the wall
with the supplied screws.
Setting It Up
