Panasonic NA-F1002B

- 17 -
9. DISASSEMBLY INSTRUCTION
NA-F78B2 / F80B2 / F80H2 / F90B2 / F90H2 / F1002B
9.1 Remove Screws of Back Panel out
9.2 Remove Back Panel out
- Take out by use screwdriver.
- Insert fi ngers through inside of Back Panel (Fig. 2).
- Pull it back a little for Hooks at upside loose (Fig. 3).
- Use the fi
nger for pull end of Hook (Fig. 5) loose from the Base Unit (Fig. 4)
- After Hook loose 1 side / We can remove it by twist Back Panel a little.
- If it is dif
fi
cult to remove / Have to use the fi nger to pull another side.
Fig. 1
Fig. 2 Fig. 3
Fig. 4 Fig. 5
