Panasonic NA-F100A2

3. SPECIFICATIONS
Model NA-F100A2
Country Thailand
Model Code W9CP
Rate voltage and Frequency 220V / 50Hz
Power Cord Unit C3
Body Colour White
Rate Power Consumption
(Wash / Spin)
220V/50Hz 400W / 220W
Power Consumption 220V/50Hz 120Wh
Standard Capacity Wash 10.0 Kg
Spin 10.0 Kg
Standard Consumption Water 160 Liter
Product Weight Accessories 38 Kg
Packing 44 Kg
Outer Dimension (mm.) Body 600 X 652 X 1034
Package 660 X 720 X 1144
Pulsator with rated load (rpm.) 95 rpm / min
Spin Tub with rated load (rpm.) 700 rpm / min
Water Supply Pressure 0.01 to 1 MPa (0.1 to 10 Kgf / cm
2
) / 1 ~ 18 liter / min.
Motor Thermo protector of the single-phase induction motor 135°C
Safety Switch Checking Unbalance
Buzzer Rings when finishing washing or unusual
Detergent Case Dispenser Usable
Fabric Softener Dispenser Usable
Filter Unit Usable
Child Safety Usable
Auto Restart Usable
Auto Power Off Usable
- 5 -
