Panasonic NA-F100H3

- 14 -
6. WIRING DIAGRAM
6.1 NA-F80B3 / NA-F80H3 / NA-F90B3 / NA-F90H3
NA-F100B3 / NA-F100H3 / NA-F1003B / NA-F1003H
( H, B SERIES )
6.2 NA-F90G3 / NA-F100G3 / NA-F1103G
( G SERIES )
CN402
Black
PS
SF
Geared
Motor
Valve unit
Grey
Yellow
Yellow
Yellow
Motor
Purple
Red
Blue
Red
Blue
Red
Blue
Blue
Brown
White
Brown
Capacitor
Black
Light Blue
Orange
1234
CN203
123
CN204
1
CN102
CONTROLLER UNIT
1
CN101
Power
Wiring a
different color
1
M
2
CN402
Black
PS
SF
Thermistor
Geared
Motor
Valve unit
Grey
Yellow
Yellow
Yellow
Motor
Purple
Red
Blue
Red
Blue
Red
Blue
Blue
Brown
White
Brown
Capacitor
Black Black
Green
Light Blue
Orange
1234
CN203
123
CN204
1
CN102
CONTROLLER UNIT
1
CN101
Power
Wiring a
different color
Connector
connection
1
M
2
NA-F80B3 / F80H3 / F90B3 / F90H3 / F90G3 /
F1003B / F1003H / F1103G / F100B3 / F100H3 / F100G3
