Ref. No. Part No. Part Name & Description Remarks
C4801 ECJ1VB1H102K C CHIP 50V 1000PF *NOTE
C4802 ECJ1VB1H102K C CHIP 50V 1000PF *NOTE
C4803 ECJ1VB1C273K C CHIP 16V 0.027UF *NOTE
C4804 ECJ1VB1C273K C CHIP 16V 0.027UF *NOTE
C4805 F1J1A1050002 C CHIP 10V 1UF *NOTE
C4806 ECJ1VB1H102K C CHIP 50V 1000PF *NOTE
C4807 ECST0GY226 TANTALUM CHIP 4V 22UF *NOTE
C4808 F1J1A1050002 C CHIP 10V 1UF *NOTE
C4809 ECJ1VB1H102K C CHIP 50V 1000PF *NOTE
C4810 ECST0GY226 TANTALUM CHIP 4V 22UF *NOTE
C4811 ECST0JY226R TANTALUM CHIP 6.3V 22UF *NOTE
C4812 ECJ1VB1H103K C CHIP 50V 0.01UF *NOTE
C4813 ECJ1VB1H821K C CHIP 50V 820PF *NOTE
C4814 ECJ1VB1H821K C CHIP 50V 820PF *NOTE
C4815 ECJ1VB1E223K C CHIP 25V 0.022UF *NOTE
C4816 ECJ1VB1E223K C CHIP 25V 0.022UF *NOTE
C4817 F1J1A1050002 C CHIP 10V 1UF *NOTE
C4818 F1J1A1050002 C CHIP 10V 1UF *NOTE
C4819 ECJ1VB1H222K C CHIP 50V 0.0022UF *NOTE
C4820 ECJ1VB1H222K C CHIP 50V 0.0022UF *NOTE
C4821 ECUE1C104ZFV C CHIP 16V 0.1UF *NOTE
COILS
Ref. No. Part No. Part Name & Description Remarks
L4801 J0JBC0000036 FERRITE BEAD CHIP *NOTE
L4802 J0JBC0000036 FERRITE BEAD CHIP *NOTE
FPC CONNECTOR
Ref. No. Part No. Part Name & Description Remarks
FP4801 K1MN07B00022 CONNECTOR 7P *NOTE
JACKS
Ref. No. Part No. Part Name & Description Remarks
JK4801 K2HC104B0017 STERO MICROPHONE JACK SOCKET *NOTE
MISCELLANEOUS
Ref. No. Part No. Part Name & Description Remarks
701 LSEK0447 ELECTORIC CONDENSER MICROPHONE UNIT *NOTE
703 LSMG0111 MICROPHONE DAMPER *NOTE
705 LSJW0033 FLEXIBLE FLAT CABLE W/OUT PLUG,4.8V *NOTE
13.3.3. FRONT C.B.A.
TRANSISTORS
Ref. No. Part No. Part Name & Description Remarks
Q6501 XP0150100L TRANSISTOR COMPLX CMP SI NPN CHIP *NOTE
Q6502 B1BCEF000003 TRANSISTOR SI PNP CHIP *NOTE
